Hot Wind Fish Dryer Oven/ Fish Cabinet Dryer/ Tray Drying machine
1. This hot wind fish dryer oven fish cabinet dryer is used for drying fish,seafood and many other sea products.There are four kinds of heating resource for choice: steam, electricity, heat conducting oil, both steam and electricity.
2. The temperature (steam heating): 50-140°C, Max 150 °C
3. The temperature (when using electricity and far-infrared): 50-300°C
4. The automatic control system or the computer control system is selectable.
5. Commonly used steam pressure 0.2-0.8 MPa (2-8kg/cm2).
6. Standard electric heating is 15kw for type CT-1,CT-C-1, easy flammable and explosive material is forbidden.
7. The special requirements should be indicated at the time of order.
8. The price for the non-standard oven should be consulted.
9. If the operation temperature is more than 140°C or less than 60°C, it should be indicated at the time of order.
10. The oven and baking tray made by our factory are uniform in the dimensions, and can be exchanged with each other
11. Explosive-proof motor and control cabinet as option.
Specification
| Model | Trolley | Tray | Inside space | Productivity | Power | Size |
| HG-1 | 1 | 24 | 5.76 | 50 kg/batch |
9 kw | 1550*800*2200 mm |
| HG-2 | 2 | 48 | 11.52 | 100 kg/batch | 12 kw | 2100*1100*2300 mm |
| HG-4 | 4 | 96 | 23.04 | 200 kg/batch | 18 kw | 2100*2000*2300 mm |
| HG-6 | 6 | 144 | 34.56 | 300 kg/batch | 22 kw | 2600*2100*2300 mm |
| HG-8 | 8 | 192 | 46.08 | 400 kg/batch | 30 kw | 4000*2000*2300 mm |
Details pictures of this machine
Package&Delivery
New commercial vegetables fruit drying machine,hot wind tray dryer will be packed in standard export wood case.
