automatic chalk piece making machine
Chalk making machine adopts Streamline Operation: Supplying water automatically, electric beater, electric grouting, mold stripping. Raw material used to product chalk can be decreased by 30% compared to the previours ones. The production capacity is improved from 50% to 99% on the basis of the traditional chalk machine.
Specification of chalk making machine
Model |
800-1 |
800-2 |
800-4 |
800-6 |
800-8 |
Capacity (psc/day) |
60000-70000 |
120000-150000 |
230000-250000 |
380000-400000 |
580000-600000 |
Mold No. |
1 |
2 |
4 |
6 |
8 |
Operator |
1 |
1 |
1 |
2 |
3 |
Mold Size (mm) |
660*500*350 |
660*500*350 |
660*500*350 |
660*500*350 |
660*500*350 |
Weight (kg) |
50 |
350 |
450 |
650 |
850 |
Remarks: the size of the chalk: the diameter of two heads are 10mm and 8mm. The length is 75mm.Or we can produce mold as your requirement.
Chalk size
Type |
Big end(mm) |
Small end(mm) |
length(mm) |
may move the length(mm) |
Circle |
9.6 |
9 |
80 |
2 |
Circle |
10 |
7.7 |
76 |
2 |
Circle |
10 |
8.1 |
75 |
2 |
Circle |
10 |
9.5 |
80 |
2 |
Circle |
11 |
10 |
100 |
2 |
Side |
12 |
11.5 |
100 |
2 |
Side |
12 |
11.5 |
80 |
2 |
Side |
11 |
10 |
60 |
2 |
Hexagon |
10 |
8 |
76 |
2 |
Hexagon |
11 |
9 |
75 |
2 |
my company had been proved and certified by TUV Rheinland company
