Help CenterGalvanized Floor Grating
Related Products
Widely applied in the power plant, the chemical plant, the refinery, the iron and steel plant, the paper mill, the machine factory, the cement plant, the municipal engineering, sewage treatment plant, environmental sanitation project as platforms, the aisle, the trestle, the ditch lid, the well lid, the ladder, the railing, the guard rail and so on.
No |
Item |
Description |
1 |
Bearing bar |
25x3,25x4,30x3,30x4,30x5,32x5,40x5,50x5,.....75x10mm |
2 |
Bear bar pitch |
12.5, 15, 20, 23.85, 25, 30, 30.16, 30.3, 34.3, 35, 40,41,60mm. US standard: 1"x3/16", 1 1/4"x3/16", 1 1/2"x3/16", 1"x 1/4", 1 1/4"x 1/4", 1 1/2"x 1/4" etc. |
3 |
Cross bar pitch |
40,45,50,76,100,101.6mm etc |
4 |
Material |
ASTM A36,A1011,A569,Q235,275 |
5 |
Surface treatment |
Black, hot dipped galvanising, paint |
6 |
Standard |
China: YB/T 4001.1-2007 |
USA: ANSI/NAAMM(MBG531-93) | ||
UK: BS4592-1995 | ||
Australia: AS1657-1985 |
1.pallet packaging 2.Strap Packaging 3.screw rod fixation 4.or others specified by customer
