Specifications
geotextile for foundation engineeringwoven geotextile fabric construction
Polypropylene woven geotextile for construction
PP woven geotextile for construction
used for water preservation,highway/railway road,air harbor project,power plant project
PP woven geotextile for construction
Produce introduction
1)Woven geotextile made on circle weave loom,
2) Materials: polypropylene and other imported new materials
3) Weight per square meter: 80-700g/m²
4)Perfect flexibility and against ultraviolet radiation and aging
Application range
It can be widely used in areas of railways, highways, sport fields, earthwork projects, tunnels, coal mines, walls and slopes, environmental protection, and so on.
All colors and sizes can be customized.
NO. |
Item |
20-1 |
530-2 |
40-2 |
850-3 |
560-4 |
280-5 |
6100-70 |
1 |
Longitude breaking strength, KN/m >= |
20 |
30 |
40 |
50 |
60 |
80 |
100 |
2 |
Latitude breaking strength, KN/m>= |
15 |
22 |
28 |
35 |
42 |
50 |
70 |
3 |
Longitude breaking elongation, <= |
28 |
||||||
4 |
Trapezoid tear strength(Latitude) KN>= |
0.3 |
0.45 |
0.5 |
0.6 |
0.75 |
1 |
1.2 |
5 |
Bursting strength, KN |
1.6 |
2.4 |
3.2 |
4 |
4.8 |
6 |
7.5 |
6 |
Vertical osmotic coefficient, cm/s |
10-1 ---10-4 |
||||||
7 |
Effective aperture O95, mm |
0.08-0.5 |
||||||
8 |
Quality per unit acreage, g/m2 |
120 |
160 |
200 |
240 |
280 |
340 |
400 |
Allowable deviation, % |
+-10 |
|||||||
9 |
Ultravioresistant strength conservation rate |
As per requirements of design or contract |
||||||
