Spiral classifier introduction:
Zhengzhou Yufeng Heavy Machinery Co., Ltd has independently developed this new generation series of classiifer, which introduce the foreign advanced technology. And it features simple structure, reliable and easy in operation. Actua, the classifier has four types:high weir single and double spiral, immersed single and double spiral calssifiers
High weir type:the top of the spiral vane is above the overflow surface, and the spiral center is under the overflow, mainly applied in classifying the size between0.83-0.15mm
Immersed type:all the spiral vanes immerses under overflow surface,mainly applied in classifier the size bet 0.15-0.07mm
Features of spiral classifier
1.Simple structure;
2.Reliable working conditons;
3.Convenient operation;
4.Even granularity.
Main technecal parameters:
Model |
Spiral diameter (mm) |
Trough length (mm) |
Spiral rotation speed |
Production capacity (t/d) |
Motor power kw<= |
Machine weight (t) |
||
Back to sand |
Overfall |
For driving |
For lifting |
|||||
FG7.5 |
750 |
5500 |
6-10 |
340-570 |
65 |
3.0 |
HM |
2.7 |
FG10 |
1000 |
6500 |
5.0-8.0 |
675-1080 |
110 |
5.5 |
HM |
4.43 |
FG12 |
1200 |
6500 |
5.0-8.0 |
1170-1870 |
155 |
5.5 |
1.5 |
8.7 |
FG15 |
1500 |
8400 |
4.0-6.0 |
1830-2740 |
235 |
7.5 |
2.2 |
12.5 |
FG20 |
2000 |
8400 |
4.0-6.0 |
3240-5400 |
400 |
11 |
2.8 |
20.5 |
FG24 |
2400 |
9210 |
3.6 |
4650-7450 |
580 |
15 |
3.0 |
25.6 |
FG30 |
3000 |
1250 |
3.2 |
11625 |
890 |
22 |
4.0 |
37.7 |
2FG12 |
1200 |
6500 |
5.0-8.0 |
2340-3740 |
310 |
5.5×2 |
1.5×2 |
14.0 |
2FG15 |
1500 |
8400 |
4-6.0 |
3660-5480 |
470 |
7.5×2 |
1.5×2 |
21.1 |
2FG20 |
2000 |
8400 |
3.0-5.5 |
7780-11800 |
800 |
11×2 |
2.8×2 |
36.5 |
2FG24 |
2400 |
9210 |
3.6 |
13600 |
1160 |
15×2 |
3×2 |
46.8 |
2FG30 |
3000 |
12500 |
2.0-3.2 |
14600-23400 |
1785 |
22×2 |
4×2 |
73.0 |
Welcome to China and welcome to visit Yufeng, if you have any other questions, you may contact with us, we will spply you the highest service as soon as quickly. Marcie Liu, Mobile:8618236781826 or skype:driermachine
...
