Specifications
1:Perfect working WSG series Sawdust Drier with CE2 6 Models, Stable Funcation
3 CE
The Sawdust Drier is a type of industrial dryer employed to reduce or minimize the liquid moisture content of the material. The dryer is made up of a large, rotating cylindrical tube, usually supported by steel beams.
WSG-Series Sawdust Drier can be used to dry the following material:
a. Sawdust, grazing, leaves, sugarcane biogases, and animals’ wastes and so on. And it can be used in Chemical Plant, Mine, Metallurgy and other industries. For example, the ore, the scoria, coal, metallic powder, phosphor fertilizer, sulfur.
b. It can dry the granule materials which have special requesting and must dry in low temperature. For example, Vesicant; Light Calcium Carbonate; Active Dust; Magnet Powder; Plumbago and so on.
During the Drying Process, the best moisture content to pellet and briquette is about 13-15% and 11-12%, the function of the Rotary Dryer is to make the crushed pieces with suitable moisture.The Rotary Dryer is made up of Direct or Indirect Biomass Stove, Main Rotary Drum Body, Screw Conveyor, Cyclones, Air-locks, Fans and matched Pipes which can realize to reduce the moisture from 60%-10%.
Storage of Sawdust Drier
Model |
WSG-250 Sawdust Drier |
WSG-500 Sawdust Drier
|
WSG-1000 Sawdust Drier |
WSG-2000 Sawdust Drier |
WSG-3000 Sawdust Drier |
Evaporation Capacity (kg/h) |
250 |
500 |
1000 |
2000 |
3000 |
Power(Kw) |
18 |
27 |
40 |
56 |
75 |
Consumption electricity(Kw) |
15 |
20 |
30 |
50 |
65 |
Damage parts and the life |
Bearing:1-2 years; Tricorn belt B model |
||||
|
Overall Size (m) |
5*1.7*1.6 |
5.5*1.8*2.3 |
6.2*2.1*3.3 |
8.9*2.6*3.7 |
9.8*3.2*4.3 |
|
Weight (ton) |
5 |
8 |
11 |
16 |
20 |
|
Coal Consumption (kg/1hour) |
80 |
140 |
280 |
350 |
600 |
