Hot Sell Wood Chip Grinder

Hot Sell Wood Chip Grinder photo-1
Hot Sell Wood Chip Grinder photo-2
US$ 500 - 3,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Mill Granularity:
25-35mm
Aperture Size:
30mesh-5cm
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Mill Granularity 25-35mm
Aperture Size 30mesh-5cm
Spindle Speed 650r/min
Number of Cutter 3
Length of Cutter 400-780mm
Cutter Diameter 300-1300mm
Inlet Diameter 180*140
Place of Origin Henan, China
Brand Name MUCHANG
Model Number MPJ-400
Dimension(L*W*H) 1500*850*1250
Weight 160+75
Certification ISO
After-sales Service Provided Engineers available to service machinery overseas

Hot sell!!wood chip grinder



Description



Wood Chipper Machine also can be called wood slicing machine.belong to the woodworking processing equipment, Mainly to meet the need of wood pulp for chemicals,and wood chips for milling wood pulp.



Disc Wood Chipper and Drum Wood Chipper

1.)mainly crushed logs,can chipping out better quality chips, widely used in pulp and paper-making mills.

2).Drum Wood Chipper can handling different wood material,can used for all kinds wood board or bark

Wood Chips regularly is :Length 15~20mm,thickness:3~5mm,not requirement on wideth, but do not exceed 20mm.



Working principle
The machine integrate blade cutting and high-speed airflow impact with collision and double crushing functions. And at the same time it could manage to complete the micro-separation processing process. In the process of blades cutting, rotor produces high-speed airflow and rotates with the blade cutting direction. The material speed up in the flow and repeatedly impact



Technical parameter





Model

power

(kw)

Capacity

(t/h)

Inlet size

(mm)

Blade Number

 Outer size

(mm)

Weight

(kg)

MPJ-400

7.5

0.5

180*140

3

1500*850*1250

160+75

MPJ-500

15

0.5-1

190*140

3

1500*950*1400

210+138

MPJ-600

18.5

1--2

190*140

3

1800*900*1400

300+174

MPJ-700

22

2.5-4

190*170

3

1900*1000*1500

360+195

MPJ-800

30

3--6

200*200

4

2100*1200*1500

450+270

MPJ-950

37

5--8

250*250

4

2300*1400*1900

800+284

MPJ-1150

55-75

6--9

300*300

6

2900*1600*2300

1200+427

MPJ-1410

90

10--15

450*450

4

3200*1800*2600

2200+667





Product exhibition

 Hot sell wood chip grinderHot sell wood chip grinderHot sell wood chip grinderHot sell wood chip grinder
