3tine Harrow, Opposed Light-duty Harrow 1BQD-2.4, 24discs,rotary Harrow, Roller Harrow,

3tine Harrow, Opposed Light-duty Harrow 1BQD-2.4, 24discs,rotary Harrow, Roller Harrow, photo-1
US$ 580 - 1,280 MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Plow & Harrow
Use:
harrow
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Shanghai port
Delivery Detail:
Delivery time depends on order quantity.
Type Plow & Harrow
Use harrow
Place of Origin Shandong, China
Brand Name TS Brand
Model Number 1BQD-2.4
Condition New

Specifications

1. working depth:100-140
2. wortking width: 240cm
3. fit with tractor 60HP
4. No.of disc: 24
5. 440kg weight

Description:



This series disc harrow  is designed and manufactured by our company combined with the foreign technology ,mainly used for crushing and loosening the soil after tillage,planing the field before seeding and mixing the soil and fertilizer etc. it features on reasonable structure,firmness for long-lasting operation,easiness to be handled and maintained,even field after tillage without deflective trailed force and so on.



model

unit

1BQD-1.6

1BQD-2.0

1BQD-2.4

1BQD-3.0

1BQD-3.6

Working width

m

1.6

2.0

2.4

3.0

3.6

Q’ty of disc



16

20

24

30

36

Working depth

mm

100-140

100-140

100-140

100-140

100-140

Overall weight

kg

330

380

440

510

580

Diameter of disc

mm

460

460

460

460

460

Matched power

hp

30

45

60

60-70

70-80

Linkage



Standard three point mounted
