Animal feed pellet production plant pellets used
Company information
Founded in 1995, Henan Zhongda feed equipment Co., Ltd is a specialized manufacturer of feed machinery, conveying equipment, storage equipment ,steel structures, food machinery
and projects of complete plants, who is engaged in independent research and development, production and sales.
Brief introduction of production plant pellets used :
The complete production plant pellets used include 8 systems
1.materials receiving and cleaning system
2.crushing system
3.automatic batching and mixing system
4.pelletizing system
oling system
6.crumbling system
7.sieving system
8.packing system
1.cleaning section:
Before going into the main equipments, he raw materials should be cleaned to remove impurities and iron parts in order to ensure the product quality and normal working of the main equipments.
2.crushing section:
Some kinds of raw materials should be grinded to small pieces. We use hammer mill to grind raw materials into small particle.
3.mixing section:
use mixer to mix the grinding raw materials to even particles. The mixer have two types: single shaft ribbon mixer and double shaft paddle mixer.
4.pelleting and cooling section:
use pellet mill to make pellet. It is equipped with feeder, conditioner and pellet mill. The feeder can control the feeding amount. Conditioner can make moisture and temperature of the feed more high, to make pelleting easily.
5.crumbling section:
Crumbling section is optional. When required pellet is small, can use crumbler to grind, such as chick feed.
6.sieving section:
We use rotary screener to sieve the pellet. It has three layers sieves.
7. Packing section:
Independent packaging system, high precision.
Machines' pictures of production plant pellets used
Main parameters of production plant pellets used :
Type |
Power of main motor |
Capacity |
Power of feeding motor |
Power of conditioner |
Diameter of ring die |
Size of finished pellets |
SZLH25 |
11*2 |
0.5-1.5 |
0.75+0.55 |
2.2 |
250 |
1.0-12 |
SZLH32 |
37 |
2-5 |
0.75+0.55 |
2.2 |
320 |
1.0-12 |
SZLH35 |
55 |
3-6 |
0.75+0.75 |
2.2 |
350 |
1.0-12 |
SZLH40 |
75 |
2-10 |
1.5+0.75 |
3 |
400 |
1.0-12 |
SZLH42 |
110 |
3-12 |
1.5+0.75 |
4 |
420 |
1.0-12 |
SZLH508 |
132/160 |
5-20 |
1.5+0.75 |
5.5 |
508 |
1.0-12 |
Pictures of production plant pellets used
20 years engineering experiences in the installation of production plant pellets used
- Our company has a professional installation team with advanced technology and rich experiences.
- We can send our technical experts to our customer's factory for engineering installation, and we will help customers adjust all the machines until everything goes well.
- We have more than 20 years installation experiences for many kinds of complete animal feed pellet production line, and every time we win customers' praises.
- So please don't hesitate to choose us, we will never let you disappointed.
Customers visit our factory
Welcome to visit our factory!
