Decorative Panel Sheet Metal
US$ 10 - 100
MOQ: 100 Square Meters
Key Specifications
Get Latest Price
Standard:
AISI, ASTM, BS, DIN, GB, JIS, Other
Grade:
Galvanized Steel Wire, Stainless Steel Wire
Thickness:
as your requirment
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hole Punch for MetalUS$ 13 - 36MOQ: 5 Pieces -
Decorative Metal Perforated Sheets/decorative Sheet for Wall/decorative Pattern Metal SheetUS$ 1 - 2.8MOQ: 100 Pieces
-
304 Stainless Steel Metal SheetUS$ 10 - 100MOQ: 100 Square Meters
-
Smoke Detector Mesh Screen for Protection/protective Mesh for Smoke Detector/smoke Detector Protective Mesh ScreenUS$ 0.05 - 0.16MOQ: 100 Pieces
-
Smoke Detector Mesh Filter/mesh Filter for Smoke Detector/smoke Detector Protect MeshUS$ 0.05 - 0.16MOQ: 100 Pieces
Standard
AISI, ASTM, BS, DIN, GB, JIS, Other
Grade
Galvanized Steel Wire, Stainless Steel Wire
Thickness
as your requirment
Place of Origin
Hebei, China
Brand Name
Yuansheng
Model Number
YS-PM-5
Type
Steel Plate
Technique
Hot Rolled
Surface Treatment
Galvanized
Application
Other, construction
Special Use
Wear Resistant Steel
Width
1-20m
Length
1-20m
decorative panel sheet metal
Specification:
(1)Cold rolled steel sheet
Thichness: 0.2mm-1mm
Length: 1m-20m
Hole Diameter: 0.8mm-10mm
(2)Plate
Thickness: 0.3mm-10mm
Size: ≤ 1.5× 3m
Hole Diameter: 0.8mm-100mm
The specification only for reference, it can be done according to the requests of the customers.
Perforated Metal hole shape: Round, Square, Long round, Triangle, Diamond, Oval, Hexangular, etc.
Perforated Metal Specification:
Thickness of Perforated Sheet: From 0.5mm to 25 mm
The Min. Hole of Perforated Metal: 1mm
The standard Size of Sheet: 1000mm*2000mm 4'*8'and 4'*10'
Plate Material |
Thickness of Metal (mm) |
Hole Dia. (mm) |
Pitch (mm) |
Sheet Width (m) |
Sheet Length (m) |
Porosity (%) |
Weight (kg/m2) |
Rolling plate |
0.2 |
6 |
2 |
1 |
20 |
44 |
0.88 |
0.35 |
5 |
4 |
1 |
20 |
24 |
2 |
|
0.45 |
6 |
3 |
1 |
20 |
35 |
2.5 |
|
0.8 |
3 |
3 |
1 |
20 |
19.6 |
3 |
|
Flat plate |
0.5 |
1 |
1 |
1 |
2 |
19.6 |
3.14 |
0.55 |
1.1 |
2.2 |
1 |
2 |
22.67 |
3.411 |
|
0.55 |
1.5 |
2.8 |
1 |
2 |
26.03 |
3.268 |
|
0.8 |
1.5 |
1.5 |
1 |
2 |
19.6 |
5 |
|
0.8 |
2.0 |
3.4 |
1 |
2 |
30.78 |
4.465 |
|
1.5 |
2 |
2 |
1 |
2 |
19.6 |
9.4 |
|
1.5 |
5.0 |
8.0 |
1 |
2 |
35.39 |
7.843 |
|
3 |
5 |
16 |
1 |
2 |
19.6 |
18.8 |
|
Stainless steel plate |
0.5 |
1 |
1 |
1 |
2 |
19.6 |
3.14 |
0.8 |
1.5 |
1.5 |
1 |
2 |
19.6 |
5 |
|
1 |
2 |
2 |
1 |
2 |
19.6 |
6.28 |
|
2 |
5 |
16 |
1 |
2 |
19.6 |
6.28 |
|
Aluminum plate |
0.5 |
1 |
1 |
1 |
2 |
19.6 |
1.08 |
0.8 |
3 |
3 |
1 |
2 |
19.6 |
1.72 |
|
1.6 |
2 |
2 |
1 |
2 |
19.6 |
3.24 |
|
3 |
4 |
16 |
1 |
2 |
19.6 |
