Home > Manufacturing & Processing Machinery > Agricultural Machinery > Forestry Machine > High Quality Sawdust Hammer Mill Machine/wood Sawdust Machine for Sale
High Quality Sawdust Hammer Mill Machine/wood Sawdust Machine for Sale
US$ 5,000 - 20,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Wood Chipper
Use:
crush
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Capacity Feed Machinery/poultry Feed MachinesUS$ 10,000 - 20,000MOQ: 1 Set -
CE Fish Feed Pellet Machine Line/fish Feed Pellet LineUS$ 2,000 - 25,000MOQ: 1 Set
-
Ce High Quality Single Screw/Twin Screw Floating Fish Feed Extruder MachineUS$ 100,000 - 150,000MOQ: 1 Set
-
Floating Fish Feed Extruder Machine Line/aquatic Feed Pellet Making ExtruderUS$ 100,000 - 150,000MOQ: 1 Set
-
Ring Mode for Pellet Mill, Circular Mould for Pellet MillUS$ 500 - 1,200MOQ: 1 Set
Condition
New
Type
Wood Chipper
Use
crush
Power Type
Electric
Production Capacity
7-11cbm/h
Place of Origin
Jiangsu, China
Brand Name
WeiFeng
Model Number
WFFS
Dimension(L*W*H)
3100x1750x1800mm
Weight
4070kg
Certification
CE
Warranty
1 Year
After-sales Service Provided
Engineers available to service machinery overseas
wood sawdust hammer mill:
This series hammer mill adopt thicken steel plate to weld, and the parts inner the grinding room which will contact the raw materials all adopt wear-resisting replaceable parts and double-wear-resisting plates, the motor and hammer mill rotors mounted together in one heavy base, and adopt the coupling for direct connection drive. The rotors have passed the dynamic balance test, and can run bi-directionally, the hammers are symmetrically arranged. The machine is simple structure, sturdiness and durability, safety and reliability, convenient operation, less vibration, high productivity.
| parameters model | 66*40 | 66*60 | 66*80 | 66*100 | 66*120 | ||||||
| Rotor diameter (mm) | 660 | 660 | 660 | 660 | 660 | ||||||
| Spindle rotate speed (rpm) | 2960 | 2970 | 2970 | 2980 | 2980 | ||||||
| Hammer line speed (m/s) | 102 | 102 | 102 | 102 | 102 | ||||||
| Grinding room width (mm) | 400 | 600 | 800 | 1000 | 1200 | ||||||
| Hammer quantity (fine grinding) | 40 | 56 | 84/116 | 120 | 136 | ||||||
| Power( kw) | 37 | 45 | 55 | 75 | 90 | 110 | 132 | 160 | 200 | 220 | |
|
Normal air volume ( m3/min) |
Fine grinding | 55 | 60 | 72 | 78 | 95 | 102 | 145 | 155 | 190 | 205 |
| Equipment resistance | Fine grinding 120~150mm H2O | ||||||||||
