Help CenterIndustrial Workshop Convection Cooling System
Related Products
Specifications
ITALY technologyreduce temperature to less than 30
change air 90 times per hour
American GATES belt
one year guarantee
Characteristics of WUSUN Poultry Equipment: exhaust fan
-Huge air volume, Low noise, Good energy saving, Little fault
-reduce the indoor temperature to less than 30, no matter how high the original temperature is.
-keep the air change 80-90 times per hour
- Wall or window mounted.
-Blade Pulley of Light weight, High intensity, Quick assemble, Anti-corrision
- Motor of 380/220V, 50HZ,3 Phase, IP 55, E Class
- Each motor is individually tested for 100% quality control.
-Our shutter can open ,close automatically and completely with the help of balancing hammer.
-the shutter can prevent dust and water effectively.
- Every ventilation fan is individually checked for quality.
Fan Item |
Exhaust fan |
1380 (50') |
1220 (44') |
1060 (37.5') |
900 (30') |
Size |
mm |
1380*1380*400 |
1220*1220*400 |
1060*1060*400 |
900*900*400 |
L*H*W | |||||
Blade Dia. |
mm |
1270 |
1110 |
950 |
770 |
Air Volume |
m3/h |
44500 |
37000 |
32000 |
28000 |
Power |
HP/KW |
1.5/1.1 |
1.0/0.75 |
0.75/0.55 |
0.5/0.37 |
Voltage |
V |
415/380/220 |
415/380/220 |
415/380/220 |
415/380/220 |
Frequency |
HZ |
50/60 |
50/60 |
50/60 |
50/60 |
Propeller Rotation Speed |
r/min |
450 |
480 |
500 |
520 |
Noise |
dB |
65 |
63 |
60 |
55 |
Weight |
kg |
85 |
65 |
55 |
50 |
Carton Size |
cm |
140*140*42 |
124*124*42 |
108*108*42 |
92*92*42 |
Loading QTY Assembled |
20'/40'GP/40'HQ |
29/60/68 |
29/64/73 |
48/112/134 |
76/160/178 |
Loading QTY Unassembled |
20'/40'GP/40'HQ |
150/240/280 |
|
|
|
