Help CenterClassic Popular 10g Sewage Water Treatment Ozonizer
Related Products
-
Efficient Portable Medical Ozonizer SterilizationUS$ 200 - 300MOQ: 1 Set -
High Quality Desktop Medical Ozone Generator/odor Remove MachineNegotiableMOQ: 1 Set
-
2013 Popular Beauty 6g Ozone GeneratorUS$ 150 - 200MOQ: 1 Set
-
2013 Hot Sales 2g to 6g Desktop Medical Ozone Generator For Hospital Or LabUS$ 200 - 300MOQ: 1 Set
-
2g 3g 5g 6g Dental Ozone GeneratorNegotiableMOQ: 10 Sets
Specifications
ceramic 10g ozonier for air purifier1.Ceramic tube
2.Timer: 0~100 hours
3.Built-in air feed
4.Built-in Auto-drying system
classic popular 10g sewage water treatment ozonizer
classic popular 10g sewage water treatment ozonizer
Parameter
Item |
Unit |
NT-T |
||||||
2G |
3G |
5G |
6G |
10G |
15G |
20G |
||
Oxygen flow rate |
LPM |
0.5~2 |
1~3 |
1.2~3 |
1.5~3.5 |
2.4~6 |
3.6~9 |
3~10 |
Ozone concentration |
Mg/L |
28~50 |
28~65 |
32~60 |
28~56 |
32~60 |
32~60 |
38.9~42 |
Ozone output |
G/Hr |
1.5~3.0 |
4~5.0 |
4.3~5.7 |
5.0~5.8 |
8.6~14.5 |
13~17 |
18.6~20 |
Power |
W |
115 |
135 |
160 |
185 |
260 |
330 |
400 |
Air flow rate (Suggested) |
LPM |
40~60 |
50~75 |
50~90 |
||||
Compressed air pressure |
Mpa |
0.025 |
||||||
Fuse of power supply |
A |
3 |
5 |
5 |
5 |
|||
Size |
cm |
36×26×61 |
40×30×77 |
|||||
Net Weight |
kg |
11.25 |
11.30 |
11.50 |
18 |
20 |
35 |
|
Noted:
1. Above ozone capacity were tested under oxygen source
2. Net weight will be 10% different for different plug
Features
>> Builted in Domestic Patented Product -Air cooling ceramic ozone generator
>> Builted in Automatic air dryer,Feed dryed air or outside oxygen source
>> ORP Measuring Range: 0~14Ph-1000~+1000mV
>> It can be Movable with wheels & Handles or Wall mounted.
>> Connect with external ozone injector for water treatment
>> Timer: 0~100 hours
>> No breakdown with easy operation and maintenance.
Control panel
ORP Monitor, Voltmeter, Ampmeter, Switch, Timer, Working light, Power light etc.
classic popular 10g sewage water treatment ozonizer
Application
>> Aquactulture,Aquarium,Fish farming Water treatment
>> Cooling towers water treatment
>> Swimming pools Water treatment
>> Water Disinfection& sterilization
Ozone Generator
>> Good diffusivity: Ozone gas can reach to everywhere without dead angle.
>> Strong sterilization ability: Ozone sterilization ability is the same with peroxyacetic acid (C2H403),which is stronger than regular disinfectant.
>> Convenient raw material: Ozone use oxygen gas as raw material, which we can get from air ambient.
>> Co-friendly: Ozone can be resolved into oxygen and oxygen atoms, so without secondary pollution.
UV Sterilizer
>> Weak penetrability, which makes the disinfection effect very weak if the UV radiation can’t reach.
>> Shorter life time: the sterilization ability decrease along with using time. And short life time 8,000~12,000 hours (China) with higher repair cost, but ozone with 20,000 hours.
>> Harmful for health: UV light is electromagnetic radiation with a wave length of 328~210nm,this could make microorganism die of losing DNA transformation ability. If UV directly onto people, it will cause skin, eyes problem, even cause skin cancer.
Is ozone harmful to human body ?
>> Once the ozone concentration fails to meet the hygiene and safety standard, we can notice with our sense of smell and dodge away or take actions to avoid further leakage.So far there is no one dealth reported caused by ozone poisoning.
Does the ozone generator work efficently ?
>> Undeniably,ozone can sterilize and remove odor and formaldehyde.It is reported that ozone is a widely used bactericide.It can kill escherichia coli,bacimethrin efficently and resolve the harmful material in a short time.
classic popular 10g sewage water treatment ozonizer
classic popular 10g sewage water treatment ozonizer
What we do?
We Provide high-quality ozone generator for :
>> Ozone generator wholesalers Retailers and oneline shops (Ebay, Amazon...)
>> OEM-The custom-made ozone generator are available.
>> Upon customer's idea, drawings, photos etc.
>> ODM-The modification of the ozone generator after customer's selection is accepted.
Excellentafter-sales service:
>> 1 year warranty again the manufacture defect, offer life time consultation on problems occurred.
>> 2M silicone tube and 2PCS air stone gift for any ozone machine order.Report on the making process.Marketing feedbacks tracing.
Why choosing us?
>> Having 7 years production experienced .We are trusty business partner.
>> Quality Controlled:Quality Control personnel check the quality at every stage of production, from the incoming raw materials to the finished product.
>> NT-T Production Capacity: 3000 pcs per month.
>> We have serial products: ozone tube ,UV water sterilizers, ozone generators, oxygen concentrators, protein skimmers, and filters, mixing pumps and other water or air treatment spare parts.
>> We supply OEM service according to customers' requests and give out professional suggestions. Distributors Offer : Welcome to be our distributor.
Professional factory of ozone generator, best quality, lowest price, good after-sale service and fast shipping !!
We are the trusty partner! Buy base on the trust !
