Venturi Injector PVDF 1/5" for Water Treatment

Venturi Injector PVDF 1/5" for Water Treatment thumbnail-1
Venturi Injector PVDF 1/5" for Water Treatment photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Other
Medium Material:
Other
Contact Supplier Request Quote Chat Now
Guangzhou Netech Environmental Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
guangzhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Other
Medium Material Other
Place of Origin Guangdong, China
Brand Name Netech
Model Number A12057

Specifications

Venturi injector PVDF 1/5" for water treatment
1. It is made of anti-ozone material, PVDF.
2. Connect with ozone generator

 Venturi injector PVDF 1/5"  for water treatment



Venturi is designed to be used with an ozone generator for water treatment. It is made of anti-ozone material, PVDF. Connected to your existing filtration system it allows an ozone injection point, where the vacuum effectively sucking the ozone gases into the water flow



Specification:









Venturi

Marks

Model

Quantity

(PC)

Size

(mm)

1

A12057

1

57

2

A25100

1

100

3

A32235

1

235

4

A25152

1

152

5

A48275

1

275

6

A58295

1

295









Specifications

Model: A12057
Material:PVD
Water flow rate:0.05-0.25 T/Hr
Specification:

1. Inlet & Outlet diameter 1/5’ external screw thread

2. Valve bonnet of Gas Inlet is 1/8’;

3. flexible hose

4. Length: 57 mm

Model: A25100
Material:PVDF
Water flow rate: 0.1-1 T/Hr
Specification:

1. Inlet & Outlet diameter 1/2’ external screw thread

2. Valve bonnet of Gas Inlet is 1/4’;

3. flexible hose is 1/4

4. Length: 100 mm

Model : A32235
Material: PVDF
Water flow rate:3-10 T/Hr
Specification:

1. Inlet & Outlet diameter 1’ external screw thread.

2. Valve bonnet of Gas Inlet is 1/2’;

3. flexible hose is 1/8

4. Length: 230 mm


Model: A25152
Material: PVDF
Water flow rate: 1~3 T/Hr
Specification:

1. Inlet & Outlet diameter3/4’ external screw thread

2. Valve bonnet of Gas Inlet is 1/4’;

3. flexible hose is 1/4’

4. Length: 152 mm

Model: A48275
Material: PVDF
Water flow rate:10~25 T/Hr
Specification:

1. Inlet & Outlet diameter 1.5’ screw thread

2. Valve bonnet of Gas Inlet is 1/2’;

3. flexible hose is 1/2’

4. Length: 275mm

Model: A58295
Material: PVDF
Water flow rate: 25~50T/Hr
Specification:

1. Inlet & Outlet diameter 2’ screw thread

2. Valve bonnet of Gas Inlet is 1.25’;

3. flexible hose is 1/2

4. Length: 295mm







Venturi injector PVDF 1/5" for water treatment



Venturi injector PVDF 1/5" for water treatment Venturi injector PVDF 1/5" for water treatment

Applications:

Venturi injector PVDF 1/5" for water treatmentVenturi injector PVDF 1/5" for water treatmentVenturi injector PVDF 1/5" for water treatmentVenturi injector PVDF 1/5" for water treatmentVenturi injector PVDF 1/5" for water treatment









Venturi injector PVDF 1/5" for water treatment
