Specifications
Ozone UV Water Filter System:1. swimming pool, aquaculture water filter system
2. automatic with smart timer
3. easy install
Ozone UV Water Filter System for Swimming Pool
Applications of ozone UV lamp sterilizer:
1> Waste water treatment
2> Swimming pool and SPA
3> Domestic water sterilizer
4> Aquaculture and aquarium
5> Space air purification
6> Ozonated water for disinfection
7> Bottle water sterilizer
8> Drinking water disinfection
9> Ozone generator for food processing
10>Decompose chemical residual from vegetable and fruit ,Eliminate bacteria and virus for agriculture products to keep fresh ,use for food processing, cold storage .
For several years researching, now we use UV & Ozone together for improving ozone dissolution ratio.
UV-O3 Disinfection system combined with ozone and ultraviolet.
1. Theory evidence:
Scientists have discovered that added UV in ozone disinfection system can stimulate activity of ozone, and catalyze ozone & water molecules to create plenty of hydroxyl radical (OH-). OH- is active material which was produced by reaction of ozone with water.
The oxidizing ability of OH- is 100 times higher than hypochlorite (OCI-).
The sterilization ability of OH- is 3000 times higher than hypochlorite (OCI-).
The sterilization ability with UV & Ozone is 1-2 times higher than use ozone individual.
2. System Structure
A. Use booster pump, injector and reaction tower for ozone mixing in water, then water return to tank. Because the irradiation of UV has greatly increased generate of OH-, OH- speeds up the oxidation and sterilization efficiency for water.
B. UV-O3 system, because it using UV, it not only have an excellent effects of sterilization & oxidation under low ozone output working condition, but also can avoid risk of high ozone concentration in aquaculture. With using UV for small size of reaction tower, there is no need to use activated carbon for ozone destructor which can save much cost.
C. UV-O3 can reduce the dosage of Chlorine. If the efficiency can match with requirements of sterilization and oxidation, the amount of Chlorine could be further decreased, combined Chlorine, free Chlorine can be respective lower than 0.2 mg/L, 0.4 mg/L in water. The Chloramines and THM have been substantially reduced to a certain extent. It will be the important part for meet with the requirements of environmental protection.
D. In UV-O3 system, OH- has strong oxygenolysis ability for organic pollutants. The production of OH- and its reaction with organic pollutant only can be carried out under UV.
E. Using UV-O3 system can save ≥40% cost than use ozone only
Specifications of ozne generator with uv lamp sterilizer system:
Model |
Specification |
Water capacity m3 |
Ozone generator (g/hr) |
Power (W) |
NT-M1 |
0.4×0.48M |
30 |
5 |
40 |
NT-M2 |
0.5×1.2M |
50-80 |
10 |
40 |
NT-M3 |
0.6×1.5M |
150-220 |
20-30 |
40-60 |
NT-M4 |
0.75×1.8M |
300-400 |
50 |
100 |
NT-M5 |
1.0×2M |
500-600 |
80 |
100 |
NT-M6 |
1.0×2M |
800 |
100 |
160 |
