Specifications
planetary mixer concrete mixer machine with lift1. ISO TUV after service
2. Different types, Customized
3. Efficient
planetary mixer planetary concrete mixer
Model: MP500
Mixing Power: 18.5kw
Charging Capacity: 750L
Discharging Capacity: 500L
Discharging Weight: 1200kg
Size: 2220 X 2071 X 1880mm
Weight: 2000kg
The hydraulic discharge power: 2.2kw
Planet/Vane: 1/2
Side Scraper: 1
Discharging Scraper: 1
Lifting Hopper Power: 4kw
Lifting Speed: 0.25m/s
Hopper Capacity: 870L/1305kg
The above is Planetary Mixer MP500 technical parameter.
Model |
MP500 |
MP750 |
MP1000 |
MP1500 |
MP2000 |
Mixing Power |
18.5kw |
30kw |
37kw |
55kw |
75kw |
Discharging Capacity |
500L |
750L |
1000L |
1500L |
2000L |
Charging Capacity |
750L |
1125L |
1500L |
2250L |
3000L |
Discharging Weight |
1200kg |
1800kg |
2400kg |
3600kg |
4800kg |
Size/mm |
2220X2071X1880 |
2581X2336X2195 |
2891X2602X2217 |
3223X2902X2425 |
3625X3230X2630 |
Weight |
2000kg |
3500kg |
6000kg |
7000kg |
8500kg |
The hydraulic discharge power |
2.2kw |
2.2kw |
3kw |
3kw |
4kw |
Planet/Vane |
1/2 |
1/3 |
2/4 |
2/4 |
3/6 |
Side Scraper |
1 |
1 |
1 |
1 |
1 |
Discharging Scraper |
1 |
1 |
1 |
1 |
2 |
Lifting Hopper Power |
4kw |
7.5kw |
11kw |
15kw |
22kw |
Lifting Speed |
0.25m/s |
0.25m/s |
0.25m/s |
0.25m/s |
0.25kw |
Hopper Capacity |
870L/1305kg |
1300L/1950kg |
1740L/2610kg |
2610L/3915kg |
3480L/5220kg |
planetary mixer planetary concrete mixer
