2013 the Lastest Motor Vibrating Feeder Used for Construction

2013 the Lastest Motor Vibrating Feeder Used for Construction thumbnail-1
2013 the Lastest Motor Vibrating Feeder Used for Construction photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
sanding making
Power Type:
Electric
Contact Supplier Request Quote Chat Now
Henan Teng Fei Machine Manufacturing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application sanding making
Power Type Electric
Capacity(t/h) 60-450t/h
Place of Origin Henan, China
Brand Name Tengfei
Model Number ZSW-490*110
Power(W) 7.5-22kw
Dimension(L*W*H) 4957*1677*1365mm
Weight 5004t
Certification BV
Warranty two years
After-sales Service Provided Engineers available to service machinery overseas

Specifications

motor vibrating feeder:
1 high capability
2 little noise
3 durability

2013 the lastest motor vibrating feeder used for construction :





ZSW series Vibrating Feeding Machine is made by the body, exciter, spring support, drives, etc. Feed tank vibration source is the vibration exciter, exciter by two eccentric axis (active and passive) and the gear pair formed by the electric motor through the V-belt driven driving shaft, then take the initiative to the shaft by passive shaft gear meshing rotation, active and passive counter rotating shaft at the same time, so that tank vibration, so that a continuous flow of materials to achieve the purpose of conveying materials.



Model

Max Feeding Size(mm)

Capacity(t/h)

Motor(kw)

Overall Dimension(L×W×H)(mm)

Weight(t)

GZD300×90

500

40-100

2×2.2

3050×1430×1550

1.5

GZD370×100

700

150-300

2×3.2

4250×1874×1130

3.64

GZD430×120

800

200-400

2×5.5

4955×2206×1120

4.2

ZSW380×96

500

100-160

11

3882×2224×2121

3.98

ZSW490×96

500

120-240

15

4957×2277×2150

5

ZSW490×110

580

120-280

15

4957×2400×2150

5.32

ZSW590×110

600

300-400

22

6000×2500×2150

6.13

ZSW600×130

750

400-560

22

6082×2580×2083

7.8

ZSW600x150

800

460-575

30

6086x2662x2186

8.7

ZSW600x180

800

600-800

37

6310x3262x2230

11.8







2013 the lastest motor vibrating feeder used for construction



2013 the lastest motor vibrating feeder used for construction
