Specifications
Construction Hoist1. widely used for construction work such as industrial and civil building construction
2. Good quality
Construction Hoist
Main Characteristic of :
With rated loading capacity of 1-4 tons and rated hoisting height of 150 meters, SC series of Construction Elevator adopt gear rack engagement, and the product is an external construction hoist. The elevator is equipped with state-patented safety device , which can brake automatically in case of accidental fall. The drive unit on top of the cage is safe and reliable and convenient height of 300m.
The elevator is widely used for construction work such as industrial and civil building construction, bridge construction, underground mining ,large chimney construction and the shipping industrial. It can be used for transporting materials or people vertically, as a permanent or half-permanent lift, or in places like warehouses and towers.
Main Technical Parameters of SC Series of Construction Hoist
Model |
SC100 |
SC100/100 |
SC200 |
SC200/200 |
SC200/200 |
SCD200/200 |
SCD200/200P |
SC200/200P |
Height (m) |
50 |
50 |
50 |
50 |
50 |
50 |
50 |
50 |
Max Installation Height (m) |
200 |
200 |
200 |
200 |
200 |
200 |
250 |
250 |
Rated Loading Capacity (kg) |
1000 |
1000/1000 |
2000 |
2000/2000 |
2000/2000 |
2000/2000 |
2000/2000 |
2000/2000 |
Rated Lifting Speed (m/min) |
36 |
36 |
36 |
36 |
36 |
36 |
0-58 |
0-58 |
Rated Passenger Number |
12 |
12/12 |
16 |
16/16 |
16/16 |
16/16 |
16/16 |
16/16 |
Motor Power (kw) |
2*11 |
2*2*11 |
3*11 |
2*3*11 |
2*3*11 |
2*2*11 |
2*2*15 |
2*3*18.5 |
Inner Dimension of Cage (m) |
3*1.3*2.2 |
3*1.3*2.2 |
3*1.3*2.2 |
3*1.3*2.2 |
3*1.3*2.2 |
3*1.3*2.2 |
3*1.3*2.2 |
3*1.3*2.2 |
650mm Mast Section Weight (kg) |
124 |
148 |
124 |
148 |
148 |
165 |
165 |
148 |
650mm Mast Section Dimension (mm) |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
650*650*1508 |
800mm Mast Section Dimension (mm) |
800*800*1508 |
800*800*1508 |
800*800*1508 |
800*800*1508 |
800*800*1508 |
800*800*1508 |
800*800*1508 |
800*800*1508 |
Counterbalance Weight (kg) |
|
|
|
|
|
1000 |
1800 |
|
Rated Hanger Lifting Capacity (kg) |
200 |
200 |
200 |
200 |
200 |
200 |
200 |
200 |
