Excavator Slewing Ring Bearing 022.25.630

Excavator Slewing Ring Bearing 022.25.630 thumbnail-1
Excavator Slewing Ring Bearing 022.25.630 thumbnail-2
Excavator Slewing Ring Bearing 022.25.630 thumbnail-3
Excavator Slewing Ring Bearing 022.25.630 thumbnail-4
Excavator Slewing Ring Bearing 022.25.630 thumbnail-5
Excavator Slewing Ring Bearing 022.25.630 thumbnail-6
Excavator Slewing Ring Bearing 022.25.630 photo-1
Excavator Slewing Ring Bearing 022.25.630 photo-2
Excavator Slewing Ring Bearing 022.25.630 photo-3
Excavator Slewing Ring Bearing 022.25.630 photo-4
Excavator Slewing Ring Bearing 022.25.630 photo-5
Excavator Slewing Ring Bearing 022.25.630 photo-6
US$ 0.1 - 100 MOQ: 10 Sets
Key Specifications
Get Latest Price
Brand Name:
CLUNT
Bore Size:
676,
Outside Diameter:
514,
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
10000
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name CLUNT
Bore Size 676,
Outside Diameter 514,
Model Number 022.25.630
Feature Cross Roller
Gear Options External Gear Only
Seals Type OPEN
Place of Origin Shandong, China
Company Information

excavator slewing ring bearing 022.25.630

excavator slewing ring bearing 022.25.630



Slewing bearing/Slewing ring bearing

duct list

1 Fout point contact ball slewing bearing

2 Double row angular contact thrust ball slewing bearing

3 Crossed cylindrical roller slewing bearing

4 Crossed taper roller slewing bearing

5 Three row cylindrical roller combination slewing bearing

6……

4.type

All types

5.packing

Wooden packing or pallet packing or according to customer’s requirement

6.materical

50Mn/42CrMo/other

7.certificates

ISO9001:2008

8. service concep

quality comes from excellence, from the profession, from the details

9.enterprise credit



"customer satisfaction enterprises in Henan Province in 2008";"Credible Enterprise. "

10.application

wind generator,Marine Crane,Offshore Crane,Harbor mobile crane,Ferris wheel,stacker,Unloader,Construction Machinery,Ladle turret,shield machine,radar,and so o











Slewing bearings is a kind of large-size bearing with special configuration which can bear axial load, radial load and tilting moment. Generally, a slewing bearing has mounting holes, lubricating holes and sealing system which can meet different needs of different machines under different working conditions.







Our slewing bearings include the following types:



4 point contact ball slewing bearing;



Double-row angular contact ball slewing bearing;



Crossed cylindrical roller slewing bearing;



Three-row cylindrical roller slewing bearing;



Ball and cylindrical roller combined slewing bearing.



These bearings can be divided with no-gear, external gear and internal gear.



Slewing bearings can meet different needs of different machines under different loads as per their types. 4 point contact ball slewing bearing can carry higher dynamic loads; Crossed cylindrical roller slewing bearing can carry higher static loads; The preload of crossed tapered roller slewing bearing can make it better support rigidity and higher rotation accuracy; three-row cylindrical roller slewing bearing can carry large load.







NO

External geared

Dimensions

Assembly dimensions

DL



mm

D

d

H

D1

D2

n

mm


mm

mm

mm

mm

mm



1

021.25.500

616

384

106

580

420

20

18


022.25.500



2

021.25.560

676

444

106

640

480

20

18


022.25.560



3

021.25.630

746

514

106

710

550

24

18


022.25.630



4

021.25.710

826

594

106

790

630

24

18


022.25.710



5

021.30.800

942

658

124

898

702

30

22


022.30.800



6

021.30.900

1042

758

124

998

802

30

22


022.30.900



7

021.30.1000

1142

858

124

1098

902

36

22


022.30.1000



8

021.30.1120

1262

978

124

1218

1022

36

22


022.30.1120



9

021.40.1250

1426

1074

160

1374

1126

40

26


022.40.1250



10

021.40.1400

1576

1224

160

1524

1272

40

26


022.40.1400



11

021.40.1600

1776

1424

160

1724

1476

45

26


022.40.1600



12

021.40.1800

1976

1624

160

1924

1676

45

26


022.40.1800



13

021.50.2000

2215

1785

190

2149

1851

48

33


022.50.2000



14

021.50.2240

2455

2025

190

2389

2091

48

33


022.50.2240



15

021.50.2500

2715

2285

190

2649

2351

56

33


022.50.2500



16

021.50.2800

3015

2585

190

2949

2651

56

33


022.50.2800







 excavator slewing ring bearing 022.25.630excavator slewing ring bearing 022.25.630excavator slewing ring bearing 022.25.630excavator slewing ring bearing 022.25.630excavator slewing ring bearing 022.25.630excavator slewing ring bearing 022.25.630
