DFFILTRI Stock Thread Connection 80um Suction Filters TF-160X80L

DFFILTRI Stock Thread Connection 80um Suction Filters TF-160X80L photo-1
DFFILTRI Stock Thread Connection 80um Suction Filters TF-160X80L photo-2
DFFILTRI Stock Thread Connection 80um Suction Filters TF-160X80L photo-3
DFFILTRI Stock Thread Connection 80um Suction Filters TF-160X80L photo-4
DFFILTRI Stock Thread Connection 80um Suction Filters TF-160X80L photo-5
DFFILTRI Stock Thread Connection 80um Suction Filters TF-160X80L photo-6
US$ 1 - 300 MOQ: 5 Units
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
DFFILTRI
Model Number:
TF-160*80L
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO DALIAN TIANJIN SHANGHAI GUANGZHOU NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Henan, China
Brand Name DFFILTRI
Model Number TF-160*80L
Product Description

Product Introduction

The cover and the lower housing of the TF series filters adopt threaded connection; filter bowl is spun on the lower housing. This filter is with check valve, by-pass valve and clogging indicator, when filter element is with drawn for washing or replaced;the check valve will close automatically to stop oil flowing out from the tank.

The TF series filters can be installed at the pump suction port ,on the top,at the side or in the bottom of the tank,filter bowl is immersed below the level of the tank, the filter head is outside the tank. This filter has these features:novel design, convenient installation, high oil-passing capacity, and small resistance, filter element cleaning and replacement is convenient.

SPECIFICATIONS FOR  TF-160*80L hydraulic oil suction filter


Product material
Housing material
Filter cover:high strength plastic end cap                                                           Filter bowl:high strength composite membrane aluminum tube
Seals
Perbunan(=NBR)
Viton(=FPM)(Customizable)
Filter medium
High strength carbon steel skeleton





Main performance parameters
Nominal flow rate
L/min
160
Type of connection
Threaded connnection
Dia
mm
20
Cracking pressure of the bypass valve
bar
Setting 0.2
Filtration rating
um
80
Type of indicator
Y=ZKF-II clogging indicator ≤DC24V
Weight
Kg
0.55
Certifications
Our Delivery

Transport of large trucks to the seaport

International transport cooperation
Our Packing
Packaging



Packaging Details
The normal package is carton,case(Size: L*W*H).or pack it according to customers special request.
Packaging



Packaging Details
The normal package is carton,case(Size: L*W*H).or pack it according to customers special request.
