New XCMG GR100 Small Motor Grader

New XCMG GR100 Small Motor Grader thumbnail-1
New XCMG GR100 Small Motor Grader photo-1
US$ 39,000 - 42,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Forward Speed(km/h):
39
Reverse Speed(km/h):
25
Contact Supplier Request Quote Chat Now
Luoyang Truemach Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Port China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Forward Speed(km/h) 39
Reverse Speed(km/h) 25
Brand Name XCMG
Model Number XCMG-GR100
Weight 7000kg
Dimension(L*W*H) 6880x2375x3150mm
Certification ISO CE
After-sales Service Provided Overseas service center available

XCMG  GR100 Motor Grader

GR100 motor grader technical specifications

Basic specification

Engine model

4BT3.9

Rated power/speed

75/2400kw/rpm

Dimension(LxWxH)

6880×2375×3150mm

Operating weight(Standard)

7000kg

Performance specification

Travelling speed ,forward

5,10,20,39km/h

Travelling speed ,reverse

8,25km/h

Tractive force(f=0.75)

41.6KN

Max. gradeability

20%

Tire inflation pressure

350KPa

Working hydraulic pressure

16MPa

Transmission pressure

1.3~1.8MPa

Operating specification

Max. steering angle of front wheels

±50°

Max. lean angle of front wheels

17°

Max. oscillation angle of front axle

±15°

Max. oscillation angle of balance box



Frame articulation angle

±27°

Min. turning radius using articulation

5.9m

Blade

Maximum lift above ground

300mm

Maximum depth of cutting

350mm

Maximum blade position angle

45°

Blade cutting angle

28°—70°

Circle reversing rotation

120°

Moldboard width X height

3048×500mm
