Grid Connected Inverter 10kWLow Loss Siemens Devices and IGBT
MPPT efficiency >99.9%
Transformerless Design
THD<3%
Grid Connected Inverter 10kW
Technical Characters
MPPT self-optimizing technology maximizes the system power generating capacity, MPPT efficiency >99.9%
System efficiency up to 97%
Lower current harmonic distortion rate, THD<3%
Double DSP control, powerful functions, super performance, high precision output, and high precision output power calculation
Excellent Electromagnetic compatibility; Inverter current double closed-loop control, the current harmonic low,non-polluting, non-impact to grid
With a load-sharing function, peak power Chopping function
Self-starting, unmanned Design
Low voltage cross through, reactive power adjustable and Active Power Derating features
RS485/232 or Ethernet communication interface; RS485 follow the Modbus communication protocol; Ethernet (Ethernet) interface supports the TCP / IP protocol support dynamic (DHCP) or static IP addresses; realizable management of for a number of inverters and the implementation of remote monitoring and diagnostics capabilities
Remote monitoring and control functions
Safe and effective, professional protection
Overvoltage protection, shortage protection, island protection, over heat protection, overload and DC grounding protections;
Standards: IEC61173, IEC 61727, IEC 60529, IEC 62109, IEC 62116-2008
Type |
Unit |
JNGC10K3 |
JNGC10K3L |
|
DC input |
Recommended max PV module |
kWp |
11 |
|
Max open circuit voltage |
V |
450 |
||
The max array input current |
A |
50 |
||
Recommend PV module serial numbers |
Pcs |
18 numbers one series(17V) |
||
Number of strings |
Pcs |
1 |
||
MPPT range |
V |
220~380 |
||
MPPT precision |
% |
99% |
||
DC voltage ripple |
% |
Vpp<10% |
||
AC Output |
Rated Out power |
kW |
10 |
|
Rated grid Voltage |
V |
400 |
||
Grid voltage range |
V |
310~450 |
||
Rated Grid Frequency |
Hz |
50/60 |
||
Grid frequency range |
Hz |
4751.5/5761.5 |
||
Power Factor |
% |
>0.99 |
||
Total Harmonic Distortion THD (Iac) |
% |
Total <3% (Rated power) |
||
System |
Isolation |
Transformer |
Without |
|
Max Efficiency |
% |
94.5% |
97.6% |
|
Europe standard Efficiency |
% |
93.5% |
96.8% |
|
Contamination Level |
IV |
|||
Self standby power consumption |
W |
< 10 |
0 |
|
Ambient temperature of using |
|
-25+55 |
||
Cooling method |
Fan cooling |
|||
Environmental humidity |
% |
0~95%,Non-condensing |
||
Altitude |
M |
< 6000 |
||
Earthquake Ability |
g |
0.2 |
||
Island protection time |
S |
<2 |
||
Grid Recover start time |
Min |
3 < t < 5 |
||
Under voltage /frequency protection |
S |
< 0.2 |
||
Noise level |
dB |
<50dB |
<40dB |
|
Protected |
Reverse polarity, shortage, anti islanding, over heat islanding, over heat |
|||
Electromagnetic compatibility |
EN50081,EN50082 |
|||
Power detection |
DIN VDE126 |
|||
Prevent Island method |
Vac, Fac |
|||
|
Communication& Mechanics |
Communication interface |
Electrical isolationRS485/232 |
||
Optional |
Ethernet/GPRS |
|||
Display |
LCD display |
|||
Waterproof and Dustproof Class |
IP20(Indoor/IP42 (outdoor) |
|||
Reference to size |
mm |
530X900 X 500 |
||
Weight |
Kg |
149kg |
63Kg |
|
Standards |
IEEE929.EN61000 |
|||
