Specifications
Super T series self priming pumps;designed for economical & trouble-free operation;
CD4MCu,316SS material;
open impeller;
XT Series pumps are designed for economical & trouble-free operation in handling solids-laden liquids and slurries. Pumps feature a large volute design which allows them to re-prime automatically in a completely open system without the need of suction or discharge check valves. And this is workable with the pump only partially filled with liquid and completely dry suction line.
Pumps will be able to handle up to 75mm spherical solids, depending on pump models. In case that pump shaft or bearings need service or repair, the entire rotating assembly can be removed without disturbing pump casing or pipelines.
Offering the same reliability and performance as the ST self-priming pump, the Super T pump provides additional advanced design features such as external shimless adjustment, dual protection of bearings and an "easy-grip" cover plate handle. The combination of different sized pumps, impeller trims and speed variations ensure that the correct capacity pump will be matched to the exact requirements of your system, whether it's a small sub-division or a large waste collection system.
Type: Super T-3
Inlet, outlet: 3"
Max. throught solids: 63.5mm
Head: 4m ~ 35m
Flow:10m³/h ~100m³/h
Speed:650rpm~ 2150rpm
Repriming lifts: 1.5m~ 7.6m
Type: Super T-4
Inlet, outlet: 4"
Max. throught solids: 76.2mm
Head: 4m ~ 35m
Flow:20m³/h ~150m³/h
Speed:650rpm~ 1950rpm
Repriming lifts: 1.5m~ 7.6m
Type: Super T-6
Inlet, outlet: 6"
Max. throught solids: 76.2mm
Head: 4m ~ 30m
Flow:20m³/h ~300m³/h
Speed:650rpm~ 1550rpm
Repriming lifts: 2.4m~ 7.6m
Type: Super T-8
Inlet, outlet: 8"
Max. throught solids: 76.2mm
Head: 5m ~ 30m
Flow:50m³/h ~550m³/h
Speed:650rpm~ 1350rpm
Repriming lifts: 2.7m~ 7.0m
Type: Super T-10
Inlet, outlet: 10"
Max. throught solids: 76.2mm
Head: 5m ~ 35m
Flow:100m³/h~ 700m³/h
Speed:650rpm ~1450rpm
Repriming lifts: 2.1m~ 6.7m
