Help CenterAutomatic 3 in 1 Juice Filling Machine/packing Machine
Related Products
-
Complete Fruit Juice Production LineUS$ 10,000 - 50,000MOQ: 1 Unit -
3 in 1 Juice Filling Equipment / Fresh Orange Juice Filling MachineUS$ 10,000 - 30,000MOQ: 1 Unit
-
Juice Pet Bottle Fill -Capping MachineUS$ 15,000 - 40,000MOQ: 1 Unit
-
Full-automatic Beverage/Juice Filling Machine of 4000B/hUS$ 10,000 - 30,000MOQ: 1 Unit
-
Fruit Juice Bottle Filling Machine /juice Filling MachineryUS$ 10,000 - 30,000MOQ: 1 Unit
PET bottle automatic hot fruit juice filling machine -- Parameter
1) The juice filling machine is mainly used for hot filling machine and sealing of green tea, black tea, and fruit juice drink.
2) Adopt PLC as center controller, make use of pressure transmitter and electromagnetism pneumatic valve to measure liquid level, and keep balance of filling pressure to insure stable liquid level.
3) Adopt new type filling valves which are especially designed for plastic bottles. The returned air and the liquid in filling tank are insulated to insure cleanliness of the filled beverages.
4). Adopt advanced magnet clutches for capping with adjustable tensional moment to insure capping safely and reliably
model |
RCGF16-12-6 |
RCGF18-18-6 |
RCGF24-24-8 |
RCGF32-32-10 |
production capacity(500ml)(b/h) |
3000 |
6000 |
10000 |
14000 |
filling precision |
≤±5MM(Liquid Level) |
≤±5MM(Liquid Level) |
≤±5MM(Liquid Level) |
≤±5MM(Liquid Level) |
feedback consumption |
≤10% |
≤10% |
≤10% |
≤10% |
polyester bottle standard(mm) |
(BottleDiameter)50-92;(Height):150-310 |
(BottleDiameter)50-92;(Height):150-310 |
(BottleDiameter)50-92;(Height):150-310 |
BottleDiameter)50-92;(Height):150-310 |
suitable cap shape |
(Plastic Screw Cap) |
(Plastic Screw Cap) |
(Plastic Screw Cap) |
(Plastic Screw Cap) |
water pressure of washing bottle(Mpa) |
0.18 |
0.18 |
0.18 |
0.18 |
wash pressure of washing bottle(kg/h) |
800 |
1600 |
2500 |
3500 |
gas sourse pressure(Mpa) |
0.6 |
0.6 |
0.6 |
0.6 |
gas consumption(m3/min |
/ |
0.3 |
0.4 |
0.5 |
total power |
5.88 |
6.68 |
7.68 |
9.18 |
total weight |
2500 |
3000 |
4000 |
5000 |
dimensions(L*W*H)(mm) |
2100×1500×2200 |
2450×1800×2200 |
2750×2180×2200 |
3600×2800×3150 |
