US$ 1,995 - 4,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Usage:
Other, Small Oil Mill Machinery Prices
Type:
Other, Small Oil Mill Machinery Prices, Coconut Oil Press Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or as customers' request
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Usage Other, Small Oil Mill Machinery Prices
Type Other, Small Oil Mill Machinery Prices, Coconut Oil Press Machine
Automatic Grade Automatic
Production Capacity 4-6tons/day
Place of Origin Henan, China
Brand Name Hento
Model Number HTO-120A
Voltage 380V
Power(W) 11kW
Dimension(L*W*H) 2100X990X1750mm
Weight 970KG
Certification TUV SGS
After-sales Service Provided Engineers available to service machinery overseas



                                  Small Oil Mill Machinery Prices



1.Machine introduction of Small Oil Mill Machinery Prices :

1.The automatic screw oil press is composed of vacuum filtration system, automatic heating device and controlling system.

2. Some parts of the oil press will be preheated before pressing, such as the press chamber, press screw and press ring.

3. During pressing, the press will filter the oil in due time.

4. This machine is matched with one controlling cabinet box to control all working process of the machines.

This machine is the quite advanced one among the processing machinery of oil plants. With smart design, advanced technique, simple installation and high robotization, the automatic screw oil pressbecomes one of the most popular selling leads in our products.

2.Technical parameters of Small Oil Mill Machinery Prices :

     Model

Screw diameter

Capacity(kg/h)

Power(kw)

Weight(kg)

Dimension(mm)

HTO-ZY95A

    95mm

    150-200

    7.5

   650

1860*1660*1680

HTO-ZY100A

    94.5mm

      150

    7.5

   750

1850*1700*1780

HTO-ZY120A

    117mm

      300

    15

  1150

2050*1800*1750

HTO-ZY125A

    117mm

    180-300

    15

   890

2050*1800*1820

HTO-ZY130A

    127mm

    400-500

   18.5

  1250

2250*1950*1900

HTO-ZY160A

    157mm

     700

    22

  1590

2300*1500*2200

Small Oil Mill Machinery PricesSmall Oil Mill Machinery Prices

 Small Oil Mill Machinery PricesSmall Oil Mill Machinery Prices
