Specifications
1.ALD Brand Concertina Razor Wire2.ISO9001:2008
3.Reliable Razor Supplier
4.Professional Razor Manufacturer
5.BTO &CBT
1 materials:
-- galvanized sheet and wire
--stainless steel sheet and wire (201,202,304,316..)
2 packing:
--water-proof paper inner,plastic weaving cloth outer
--wooden pallet
--metal pallet
--by carton
3.types and specifications:
Razor blade specification | ||||||
Reference number |
Blade style |
Thickness (mm) |
Wire dia. (mm) |
Barb length (mm) |
Barb width (mm) |
Barb spacing (mm) |
BTO-12 |
|
0.5±0.05 |
2.5±0.1 |
12±1 |
13±1 |
26±1 |
BTO-18 |
|
0.5±0.05 |
2.5±0.1 |
18±1 |
15±1 |
33±1 |
BTO-22 |
|
0.5±0.05 |
2.5±0.1 |
22±1 |
15±1 |
34±1 |
CBT-65 |
|
0.6±0.05 |
2.5±0.1 |
65±2 |
21±1 |
100±2 |
Specification | ||||
Outside diameter |
No. of loops |
Standard length per coil |
type |
notes |
450mm |
33 |
8M |
CBT-65 |
Single coil |
500mm |
41 |
10M |
CBT-65 |
Single coil |
700mm |
41 |
10M |
CBT-65 |
Single coil |
960mm |
53 |
13M |
CBT-65 |
Single coil |
450mm |
112 |
17m |
BTO-12.15.20.22 |
Cross type |
500mm |
102 |
16M |
BTO-12.15.20.22 |
Cross type |
600mm |
86 |
14M |
BTO-12.15.20.22 |
Cross type |
700mm |
72 |
12M |
BTO-12.15.20.22 |
Cross type |
800mm |
64 |
10M |
BTO-12.15.20.22 |
Cross type |
960mm |
52 |
9M |
BTO-12.15.20.22 |
Cross type |
| ||||
the blade production machine
the blade products
add board line
razor barbed wire products
razor barbed wire show
razor barbed wire using
