Help CenterHTK New Type Aluminum Wire Drawing Machine
Related Products
-
High Speed HTK 6.5mm -1.5mm Low Carbon Steel Wire Drawing MachineUS$ 16,500 - 56,000MOQ: 1 Set -
Hot Sale Best Price Advanced Global Sales of Straight Line Steel Wire Drawing MachineUS$ 16,500 - 56,000MOQ: 1 Set
-
Low Carbon Steel Wire Drawing Machine (factory)US$ 16,500 - 56,000MOQ: 1 Set
-
Carbon Steel Wire/Iron Wire Drawing MachineUS$ 16,500 - 56,000MOQ: 1 Set
-
High Quality 5 Layers Pulley Type Wire Drawing MachineUS$ 16,500 - 56,000MOQ: 1 Set
Specifications
aluminum wire drawing machine1.Direct factory
2.Max incoming dia.: 8mm
3.Min outgoing dia.:1.1mm
4.ISO9001,BV certification
Aluminum wire drawing machine
HTK'S Wire Drawing Machine is one of our main products,it has the advantage of easy control,low in nosie,low cost with high effiency, we have two senior engineers, 10 senior technicians ,we have a good reputation of after-sale service in our customer.
The specification of Wire Drawing Machine
|
Item
|
Unit |
8/80 |
10/560 |
10/550 |
10/450 |
Capstan dia |
mm |
600 |
560 |
550 |
450 |
Material strength |
Mpa |
1150 |
1150 |
900 |
1300 |
Max incoming dia |
mm |
8-6 |
6.5 |
6.5 |
3.6 |
Min outgoing dia |
mm |
3-2 |
1.8 |
1.8 |
1.1 |
Total compressibility |
% |
85 |
92.33 |
92.33 |
90.7 |
Max line speed |
m/min |
300 |
400 |
400 |
400 |
Single motor power |
kw |
37-30 |
30-18.5 |
22-15 |
18.5-7.5 |
Weight |
kg |
3000 |
2500 |
2200 |
2000 |
Dimensions |
m |
2x1.2x2.6 |
1.7x1.1x2.4 |
1.52x0.82x2.3 |
1.52x0.82x2.2 |
Max average compressibility |
% |
25 |
25 |
25 |
21 |
Notes: 1. Guarantee period: one year
2. Engineer s can install, test and adjust the machine for you.
3. 24 hours online service
