Crawfish Wire

Crawfish Wire photo-1
US$ 0.1 - 5 MOQ: 100 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
Yulong
Model Number:
20044
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name Yulong
Model Number 20044
Material Other, Galvanized Iron Wire, Galvanized Iron Wire
Type Other, hexagonal wire mesh
Application Fence Mesh
Hole Shape Hexagonal
Aperture 3/8'' - 4''
Wire Gauge 0.7 - 1.6mm

Specifications

vinyl coated crawfish wire
made of low carbon Iron Wire, the mesh is firm in structure and has flat surface

vinyl coated crawfish wire

Hexagonal Wire Netting (Chicken/Rabbit/Poultry Wire) is made of low carbon Iron Wire, the mesh is firm in structure and has flat surface. It is extensively used in INDUSTRIAL AND AGRICULTURAL CONSTRUCTUONS AS REINFORCEMNET AND FENCING. It is also used as Fence for Poultry Cage, Fishing, Garden and Children playground, etc.

  • DIN1200
  • EN10223-2: 1997
  • ES1485: 1993

    Assortments Available:

    • Electro Galvanized before Weaving
    • Electro Galvanized After Weaving
    • Hot Dipped Galvanized before Weaving
    • Hot Dipped Galvanized after Weaving
    • PVC Coated Before or After Weaving
    • Stainless Steel Wire
    • Galvanized Drawn Iron Wire

    Galvanized hexagonal wire netting
    mesh Min. Gal.v.

    G/SQ.M

    Width
    Wire Gauge (Diameter)

    BWG

    Inch


    mm Tolerance(mm)
    3/8" 10mm ±1.0 0.7mm - 145 2' - 1M 27, 26, 25, 24, 23
    1/2" 13mm ±1.5 0.7mm - 95 2' - 2M 25, 24, 23, 22, 21
    5/8" 16mm ±2.0 0.7mm - 70 2' - 2M 27, 26, 25, 24, 23, 22
    3/4" 20mm ±3.0 0.7mm - 55 2' - 2M 25, 24, 23, 22, 21, 20, 19
    1" 25mm ±3.0 0.9mm - 55 1' - 2M 25, 24, 23, 22, 21, 20, 19, 18
    1-1/4" 31mm ±4.0 0.9mm - 40 1' - 2M 23, 22, 21, 20, 19, 18
    1-1/2" 40mm ±5.0 1.0mm - 45 1' - 2M 23, 22, 21, 20, 19, 18
    2" 50mm ±6.0 1.2mm - 40 1' - 2M 23, 22, 21, 20, 19, 18
    2-1/2" 65mm ±7.0 1.0mm - 30 1' - 2M 21, 20, 19, 18
    3" 75mm ±8.0 1.4mm - 30 2' - 2M 20, 19, 18, 17
    4" 100mm ±8.0 1.6mm - 30 2' - 2M 19, 18, 17, 16

    Note:
    1.) The above tolerance comply with standard EN10223-2:1997;

    2.) Minimum Galvanization is only for typical wire diameter as stipulated separately in the column for your reference; Also it is only for hot dipped Galvanized Netting.



    PVC Coated Hexagonal Wire Netting
    Mesh Wire Gauge (MM) Width
    Inch MM - -
    1/2" 13mm 0.6mm - 1.0mm 2' - 2M
    3/4" 19mm 0.6mm - 1.0mm 2' - 2M
    1" 25mm 0.7mm - 1.3mm 1' - 2M
    1-1/4" 30mm 0.85mm - 1.3mm 1' - 2M
    1-1/2" 40mm 0.85mm - 1.4mm 1' - 2M
    2" 50mm 1.0mm - 1.4mm 1' - 2M
    Five Star also offer other specifications you need

    Note: The thickness of PVC Coating is usually 0.2-0.4mm, others may arranged as per buyers request;
    Package: Normally each roll packed in water proof paper, then in termo foil (Shrinked Plastic);
