Home > Manufacturing & Processing Machinery > Engineering & Construction Machinery > Excavator > Chinese Hydraulic Excavator SW210E

Chinese Hydraulic Excavator SW210E

Chinese Hydraulic Excavator SW210E thumbnail-1
Chinese Hydraulic Excavator SW210E thumbnail-2
Chinese Hydraulic Excavator SW210E photo-1
Chinese Hydraulic Excavator SW210E photo-2
Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
PengPu
Model Number:
SW210E
Contact Supplier Request Quote Chat Now
Luoyang Mingyang Engineering Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
ShangHai/TianJin/Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name PengPu
Model Number SW210E
Condition New
Moving Type Crawler Excavator
Operating Weight 21470kg
Bucket capacity 0.9m3
Maximum Digging Height 9489mm
Maximum Digging Depth 6638mm
Machine Weight 21470kg
Max Digging Radius 9910mm
After-sales Service Provided Engineers available to service machinery overseas

Cummins turbocharged engine(original)

*Top class technology of the world with powerful drive and low noise

*The total fuel consumption of the machine is evidently lower than other machines of its kind, compliant with Tier 2 emission standards, energy saving and environmental friendly

*Imported cyclone air cleaner prolongs lifetime, redues the maintenance cost

Chinese Hydraulic excavator SW210E



High strengthened undercarriage

*The strengthened X-shape box structure fraame is wholly welded and connected by the low stress, high strength steel plate to ensure the strength and reliability

*High strengthened structure for rough terrain and lengthened type for swampy place

Chinese Hydraulic excavator SW210E



Quality bucket

The cutting blade adopts high-strenght wear-resistance steel plate, bucket teeth and side teeth are made of special material by professional refined foundry, which greatly improves bucket waribility

Chinese Hydraulic excavator SW210E



SW210E EXCAVATOR SPECIFICATION

NO.

DESCRIPTION

SPECIFICATON



1

Main machine



(1)

Working weight

21470kg

(2)

Bucket capacity

0.90M3

(3)

Track width

600mm/800mm

(4)

Transport dimension

9540*2980*3020(mm)

(5)

Overall dimension

Length of track on ground

3650mm

Ground clearance of counter weight

1070mm

Total length

9540mm

Total height

3130mm

Total width

2980mm

Track gauge

2380mm

Min. ground clearance

490mm

Track width

600mm

Track height

945mm

Tail swing radius

2810mm

(6)

Working range

Max. working radius

9910mm

Max. digging depth

6638 mm

Max. vertical digging depth

6057 mm

Max. digging height

9489mm

Max. dump height

6672mm

Min. swing radius

3650mm

(7)

Performance

Ground pressure

44Kpa/35Kpa
