SW60E Hydraulic Crawler Excavator Bucket

Name: SW60E Hydraulic Crawler Excavator Bucket
Brand: Luoyang
SKU: 140742742

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Henan, China

Brand Name:

Luoyang

Model Number:

SW60E

Luoyang Mingyang Engineering Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name Luoyang

Model Number SW60E

Condition New

Moving Type Crawler Excavator

Operating Weight 6100kg

Bucket capacity 0.22m3

Maximum Digging Height 6040mm

Maximum Digging Depth 3850mm

Machine Weight 6100kg

Max Digging Radius 6150mm

Specifications

total weight:6100kg
engine: YANMAR 4TNV94L-SFN
rater power: 39kw(53hp)/2200rpm
Bucket Capacity: 0.22m3

SW60E HYDRAULIC EXCAVATOR

Technical Parameters:

No.	Item			Parameters
1	Main parameters
	(1)	Engine		YANMAR
	(2)	Rated power		39kw/2200rpm
	(3)	Operating weight of total machine		6100kg
	(4)	Bucket capacity		0.22M³
	(5)	Width of track shoes		400mm
	(6)	Overall dimension	Length of track on ground	2000mm
			Length of track	2495mm
			Ground clearance of counter weight	720mm
			Tail swing radius	1650mm
			Total length	5900mm
			Total height(boom)	2660mm
			Total width	2025mm
			Track gauge	1600mm
			Min ground clearance	340mm
			Height of track shoes	610mm
			Top width	2000mm
			Dozer (W*H)	2000*375mm
	(7)	Working range	Max working radius	6150mm
			max working radius on ground	6110mm
			Max digging height	3850mm
			Max digging depth	6040mm
			Max dump height	4250 mm
			Max swing radius	2310mm
	(8)	Performance	Ground pressure	37Kpa
			Swing speed	9.9r/min
			Traveling speed high/low	4.3/2.3km/h
			Grade ability	35°
			Bucket digging force	39KN
	(5)	Engine	Model	YANMAR 4TNV94L-SFN
			Type	4 cycle inline water-cooled diesel
			Rated power	39KW/2200rpm
	(6)	Hydraulic system	Type of hydraulic main pump	Variable displacement piston pump fixed displacement gear pump
			Type of hydraulic pilot pump	Fixed displacement gear pump
			Main safety valve adjusted power	21.6Mpa
			Travel axial piston motor	2* variable flow axial piston motor
			Motor for swing	1*variable flow axial piston motor
