Specifications
Diesel Water Pump,Aluminum2 inch,3 inch,4 inch
Hand & Electrical start
Model |
DP30 |
Suction,discharge port diameter[mm(in)] |
80(3") |
Rated total head (m) |
13 |
Max. total head (m) |
25 |
Self-priming time (s/4m) |
120 |
Max suction head (m) |
8 |
Cont.capacity (m3/hr) |
30 |
Max. capacity (m3/hr) |
55 |
Fuel tank Capacity(L) |
3.5 |
Enigine model |
YM178F |
Type |
Single-cylinder,vertical,4-stroke air-cooled diesel engine |
Bore X Stroke (mm) |
78×62 |
Fuel |
Summer:0# Winter: -10# |
Lubricatiom Oil Model |
SAE10W-30(above CD grade) |
Lubricatiom oil volume(L) |
1.1 |
Fule oil consumption rate(g.kw/h) |
441 |
Displacement(L) |
0.296 |
Power/ speed:KW, r/min |
4/3600 |
Compression Ratio: |
20 |
Noise level(dB(A)/7m) |
74 |
Oil alert |
Yes |
Connecter of infall,Connect of outfall |
Yes |
Fiffer |
Yes |
Seal ring |
Yes |
Hoop |
Yes |
Dimension:mm |
590×480×585 |
Dry weight(kg) |
48 |
20FT |
192 |
Luxury big fuel tank |
optional |
Electrical start |
optional |
30Ah MF Battery |
optional |
We reserve the right to change specifications without notice | |
