Drill Pipe Float Valves are normally installed in a standard bore-back of the bit sub, to provide fluid flow control at the bottom of the drill stem. It also prevents backflow of cuttings from plugging the drill bit jets while making connections.
Drill Pipe Float Valve Specification:
| Type | Dia. of Valve Assembly | Length Of Valve Assembly | Dia. Of Float Recess | Sub Box | Other Popular Connections | ||
| Connection | Depth Of Recess | Connection | Depth Of Recess | ||||
| mm(inch) | mm(inch) | mm(inch) | API | mm(inch) | API | mm(inch) | |
| 1R | 42.1(1-21/32) | 149.2(5-7/8) | 42.9(1-11/16) | 2-3/8Reg. | 231.8(9-1/8) | NC23 | 231.8(9-1/8) |
| 2F-3R | 61.1(2-13/32) | 165.1(6-1/2) | 61.9(2-7/16) | 3-1/2Reg. | 266.7(10-1/2) | NC31 | 260.35(10-1/4) |
| 3-1/2 F | 79.4(3-1/8) | 254(10) | 80.2(3-5/32) | NC38 | 362.0(14-1/4) | ||
| 4R | 88.1(3-15/32) | 211.1(8-5/16) | 88.9(3-1/2) | 4-1/2Reg. | 325.4(12-13/16) | NC44 | 331.8(13-1/16) |
| 5R | 98.4(3-7/8) | 247..7(9-3/4) | 99.2(3-29/32) | 5-1/2Reg. | 374.7(14-3/4) | NC50 | 368.3(14-1/2) |
| 5F-6R | 121.4(4-25/32) | 298.5(11-3/4) | 122.2(4-13/16) | 6-5/8Reg.. | 431(17) | 5-1/2IF | 431.8(17) |
