UDM5080 Drilling And Milling Machine

Name: UDM5080 Drilling And Milling Machine
Brand: EAGLE
SKU: 140924660

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

Used

Place of Origin:

Shandong, China

Brand Name:

EAGLE

Eagle Industries, Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Qingdao China

Delivery Detail:

Delivery time depends on order quantity.

Condition Used

Place of Origin Shandong, China

Brand Name EAGLE

Model Number UDM5080 Drilling And Milling Machine

Type Universal

CNC or Not Normal

Certification CE

Specifications

UDM5080 Drilling And Milling Machine

UDM5080 Drilling And Milling Machine

Model	UDM 5080	UDM 5080A	UDM 5080B
Max.drilling dia.(MT4 taper)	50	50	50
Max.end milling width	100	100	100
Max.vertical milling dia.	25	25	25
Max.tapping dia.	M16	M16	M16
Distance from spindle nose to table surface(mm)	90-490	70-420	70-420
Spindle speed range	230-1825	110-1760	110-1760(V) 58-1355(H)
Spindle travel	120	120	120
Table size	800×240	800×240	800×240
Table travel	400×230	400×230	400×230
Overall dimensions	1110×1100×2080	1290×1140×2100	1290×1220×2100
Main motor power	0.85/1.5	0.85/1.5	0.85/1.5
N.W/G.W	610/770	610/770	610/770
Item No.	141010	141012	14015

Standard accessories		Universal Drilling/Milling Machine
Drill chuck		UDM 5080, belt drive on spindle
Inner-haxagonal spanner		UDM 5080A,gear drive on spindle
Wedge shifter		UDM 5080B,gear drive on spindle and horizontal spindle
Reduction sleeve
Draw bar
Spindle bar
wrench
Milling chuck
Boring bar
Operation manual		Optional accessories:
Quality certificate		Dividing head FW80
Packing list		Rotary table TS160
Horizontal milling bar (only for DWM 5024B)
