Help CenterChina Heavy Mining Truck With 60 t Rated Load ,Model MT86 Mining Dump Truck
Related Products
-
China UK-12 Underground Articulated Mining Truck for SaleUS$ 1 - 50,000MOQ: 1 Unit -
2016 China Brand Mining Truck LGMG MT86 for SaleUS$ 90,000 - 96,000MOQ: 1 Set
-
Lgmg 50 Ton Tire Mining Truck for Sale MT50 With Best QualityUS$ 50,000 - 80,000MOQ: 1 Unit
-
Lgmg 70T Mining Truck MT76 Mining Equipment With Best QualityUS$ 80,000 - 90,000MOQ: 1 Unit
-
MINING EQUIPMENT China MT50 50T TRUCKUS$ 60,000 - 70,000MOQ: 1 Unit
SDLG Small mining truck ,model MT86/86C with 50t rated load .
1. The reinforced riveted frame with large cross section is fabricated from high strength steel plates, ensuring large loading capacity, good shock and twisting resistance.
2. The transmission, specially developed for mining operations, is featured large torque output, and is more adaptive to harsh working conditions.
3. By applying dual push rods, rubber shock blocks and adding leaf spring plates, the front suspension is greatly strengthened.
4. Box-section stiffeners wedged to form a frame structure for the body, and abrasion resistant steel applied, better impact and abrasion resistance.
5. Driver's cab strengthened by roll-over protection structure, which is derived from excavator technique. The cab is optimized from all-around way, making it safe and comfortable.
dump truck ,nissan dump truck , dump truck for sale in dubai
Parameter of SDLG 88T Mining truck:
| Model | MT86 |
|---|---|
| Curb Weight (kg) | 28000 |
| Gross Weight (kg) | 88000 |
| Payload (kg) | 60000 |
| Body Volume (m³) | 34 (Without tailgate) |
| Truck Dimension (L*W*H) (mm) | 8670×3390×3885 |
| Wheelbase (mm) | 3800+1500 |
| Drive Mode | 6×4 |
| Min. Curving Radius (m) | ≤11 |
| Approach/Departure Angle | 30/40° |
| Max. Speed (km/h) | 57 |
| Max. Gradeability (%) | 36 |
| Engine Model | WD12.420 |
| Engine Power (kW) | 309 |
| Transmission | 10JSD220(A) |
| Tire | 14.00-25 |
| Axle Bearing Capacity (t) | 19+37+37 |
SDLG is a leading company engaged in equipment manufacturing. The main business of SDLG covers 6 areas: mining machinery ,engineering machinery ,agricultural machinery ,logistics machinery ,tire and spare parts industry ,MT86 mining dump truck
Our services : Provide good quality machinery in China and spare parts for your machines from China . transmission 4WG200/6WG200 and parts,Hanzhou Advance(Hanchi advacne) 4WG180/6WG180, Weichai ,Yuchai ,Shangchai Engine & Parts.All SDLG parts are available and fast delivery in China.
SHANDONG SENXIN TRADE CO.,LTD has been in this sector for 14 years , mainly exporting and distributing China faoums construction machinery and parts , Brands including SDLG ,XCMG ,LIUGONG,XGMA,CHENGGONG,CHANGLIN,SHANTUI,etc .
Our products:
Wheel loader , Hydraulic excavator ,Motor Grader ,Backhoe loader ,Road roller ,Skid steer loader ,Truck crane
Full series parts for those machine are available , please provide parts number to us when you go for the parts.
SHANDONG SENXIN TRADE CO.,LTD
Add:Room B2410,Kaiyuanshangcheng Building,Linyi City ,Shandong P.R ,China
TEL:+86-539-8180952
FAX:+86-539-8180952
Skype ID:senx.martin (Martin Lee)
