2. The transmission, specially developed for mining operations, is featured large torque output, and is more adaptive to harsh working conditions.
3. By applying dual push rods, rubber shock blocks and adding leaf spring plates, the front suspension is greatly strengthened.
4. Box-section stiffeners wedged to form a frame structure for the body, and abrasion resistant steel applied, better impact and abrasion resistance.
5. Driver's cab strengthened by roll-over protection structure, which is derived from excavator technique. The cab is optimized from all-around way, making it safe and comfortable.
| Model | MT86 |
|---|---|
| Curb Weight (t) | 28.5 |
| Gross Weight (t) | 88.5 |
| Payload (t) | 60 |
| Body Volume (m³) | 34 (Without tailgate) |
| Truck Dimension (L*W*H) (mm) | 8670×3390×3885 |
| Wheelbase (mm) | 3800+1500 |
| Drive Mode | 6×4 |
| Min. Curving Radius (m) | ≤11 |
| Approach/Departure Angle | 30/40° |
| Max. Speed (km/h) | 57 |
| Max. Gradeability (%) | 36 |
| Engine Model | WD12G420E211/WP12G430E310 |
| Engine Power (kW) | 420/430 |
| Transmission | 7DS200K |
| Tire | 14.00-25 |
| Axle Bearing Capacity (t) | 19+35+35 |
Mining related equipment
About Payment item:
T/T 30% in advance, the balance should be paid before shipment.
Or Letter of Credit at sight.
About after-sale service:
*We supply 1500 working hours or 12 months warranty since the bill of lading date, whichever comes first.
*During the warranty period, we guarantee to provide technical support and
spare parts (caused by quality problem) freely, but the transportation cost shall be borne by the buyer.
*Out of warranty period, we will provide the main component parts for 7 years, and the other parts for 5 years, all the cost shall be be borne by the buyer.
