Flotation Machine can be used to separate non-ferrous metal, ferrous metal, noble metal, non-metallic mine, chemical material. It can be used in roughing, scavenging, selection or reverse flotation.In the flotation process, after being mixed with drug, some qualified mineral attaches on bubble, floats on the surface of slurry and is scraped out, other mineral still stays in the slurry, so the separating purpose is finished.
2. Features of Flotation Machine
1).Large inhaling capacity and low consumption.
2).Complete flotation circuit with inhaling air and slurry, no auxiliares are needed.
3).Process is easy to be changed.
4).Reasonable circulation of slurry decreases coarse sand sedimentation.
5).Automatic controlling device makes adjustment more convenient.
3. Flotation Machine Technical Parameter:
Model |
XJK-0.35(3A) |
XJK-0.62(4A) |
XJK-1.1(5A) |
XJK-2.8(6A) |
XJK-5.8(7A) |
||
Effective cubage(m 3 ) |
0.35 |
0.62 |
1.1 |
2.8 |
5.8 |
||
Production capacity(m 3 /min) |
0.18-0.4 |
0.3-0.9 |
0.6-1.6 |
1.5-3.5 |
3-7 |
||
Rotation speed(r/min) |
470 |
400 |
330 |
280 |
240 |
||
Blade diameter(mm) |
300 |
350 |
500 |
600 |
750 |
||
Motor |
Model |
Rotor |
Y90L-4 |
Y100L2-4 |
Y132M2-6 |
Y160L-6 |
Y200L2-6(Y225M-6) |
Scraping plate |
Y90S-4 |
Y90S-4 |
Y90S-4 |
Y90S-4 |
Y90L-4 |
||
Power(kw) |
Blade Motor |
1.5 |
3 |
5.5 |
11 |
22(30) |
|
Scraping plate Motor |
1.1 |
1.1 |
1.1 |
1.1 |
1.5 |
||
Weight(t/single trough) |
0.43 |
0.86 |
1.38 |
2.33 |
3.533 |
||
Thanks so much for you taking time to browse gold ore flotation machine. Any further questions, please feel free to contact us and we are ready to so service for you!
