Help CenterMineral Water Bottle Filling Machines
Related Products
Specifications
mineral water filling machine1.material: sus304
2.bottle size:0.25L-2L
3.capacity:1000-30000BPH
Detailed Product Description
1.material: sus304
2.bottle size:0.25L-2L
3.capacity:1000-30000BPH
4.package:wooden case
MINERAL WATER FILLING MACHINE
This machine has washer, filler, and capper three functions in one body; it is automatic in total process, suitable for PET bottled mineral water, pure water and many other no gas containing drinks. It makes by high quality SUS304, key parts are precision machined by NC tool. The total machine uses advanced photoelectric detection technology to detect each part’s operation status, no bottle no filling, and no bottle no capping, automatic and easy operation.
Main features of the equipments
1. Using the wind sent access, with clamp hanging the bottle neck; which can keep the bottle shape and high-speed.
2. Bottles transmission adopts clip bottleneck technology, clean and fast.
3. Filling uses liquid cylinder feeding structure, filling valve uses new normal pressure filling, ensure the filling correct and stable,
4. Spiraling decline when output bottle, transform bottle no need to adjust the height of conveyor chains. Cap automatically.
5. Host adopts advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON.
Technical data | ||||
Model |
CGF14125 |
CGF18186 |
CGF24248 |
CGF323210 |
Number of washing, filling, capping |
14-12-5 |
18-18-6 |
24-24-8 |
32-32-10 |
Capacity; |
3000-4000 |
5000-7000 |
8000-12000 |
12000-15000 |
Suitable bottle size (mm) |
φ=50-108 H=170-340 250ml-2L |
|||
Pressure (kg/cm2) |
2~3 |
|||
Power (kw) |
Total motor 5kw |
Total motor 5kw |
Total motor 6kw |
Total motor 8kw |
Overall size (mm) |
2100x1400x2500 |
2460x1720x2650 |
3100x2100x2650 |
3500x2500x2650 |
Weight(kg) |
2500 |
3500 |
4200 |
5500 |
Technical data | |||
Model |
CGF404010 |
CGF505012 |
CGF606015 |
Number of washing, filling, capping |
40-40-12 |
50-50-12 |
60-60-15 |
Capacity; |
16000-20000 |
20000-24000 |
25000-30000 |
Suitable bottle size (mm) |
φ=50-108 H=170-340 250ml-2L |
||
Pressure (kg/cm2) |
2~3 |
||
Motor power (kw) |
total motor 12KW |
total motor 15kw |
total motor 18kw |
Overall dimension(mm) |
4600x1800x2650 |
5200x4500x3400 |
6500x4500x3400 |
Weight(kg) |
6800 |
7600 |
9800 |
