Pneumatic Filling Machine For Cream/Paste G1WG
Piston pneumatic Filler is of wide applicability and can be used for dosing filling of creams and liquids in the fields of daily chemistry, food and beverage, pharmacy, chemistry and so on. Inquire the manufacturer about other uses. Any damage due to misuse is out of limitation of warranty of the manufacturer. Such risks shall be borne by the user solely.Strictly following the instruments is a part of operation requirements.
This machine is of reasonable structure, reliable performance and accurate quantification. It applies pneumatically-driven structure. The shell and all the parts connected with filling materials are made of stainless steel (SS304 is used for standard ones and SS316 can also be customized). The inner walls of
main parts are mirror-polished in roughness Ra≤0.2-0.4µm, which conforms to the requirements of GMP certification. Therefore, it is rustless and corrosion resistant. In addition, the user can adjust the filling volume and speed within the type limitation as required.
1.Be used for filling with particulate matter sauce,paste,liquid and other material;
2.Some of the materials used 304 stainless steel;
3.Full pneumatic control, easy to operate,remove and clean; Ideal equipment for filling inflammable, explosive materials.
| Fillable range | 10-100ml,50-500ml,100-1000ml |
| Filling speed | ≤3000pcs/Hour |
| Air pressure | 0.4MPa |
| Material | Stainless steel |
| Automatic Grade | Semi-Automatic |
| Filling accuracy | ±1% |
| Air pressure range | 4-6kg/cm2 |
| Power | pneumatic |
| Filling head | Single head or Double Head or Customized |
| Shipping package size | 950×420×380mm |
Package List
Safe package: carton+foam or wooden case
Shipping package size:950×420×380mm
Tank shipping package size 450×450×500mm
Place of Origin:Guangdong China (Mainland)
Net weight : 45KG
Gross weight : 50KG
Please see the video about the machine in the following link:
/watch?v=2nw3CXi_0SM
| Model | G1WY | G2WY | G1WG | G2WG |
| Voltage | AC22/110V 50/60Hz | |||
| Air Pressure Needed(Mpa) | 0.4-0.6 | |||
| Filling Speed(Bottles/min) | 5-25 | 10-50 | 5-25 | 10-50 |
| Filling Accuracy | ≤±1% | |||
| Power(w) | 20 | 50 | 20 | 50 |
| Available Filling machine(ml) | 5-100, 10-300, 50-500, 100-1000, 500-2500, 1000-5000 | |||
