Composite tube filling+ sealing machine
Overview
__________________________________________________________________________________________________
Plastic composite hose filling and sealing machine made of stainless steel, using the buttons to control the work process: artificial tubes, automatic rotary,quantitative filling, automatically cut off, heating sealing, cut tail, finished exit.
All work using the full cylinder stroke control, easy to adjust filling volume, the filling speed can be adjusted.
It applies to all kinds of plastics and composite hose filling, sealing, date printing, cut tail. Sealing neat appearance, sealing strong, high accuracy, good stability.
Specifications
______________________________________________________________________________________
Compressed air |
Pressure: 0.4-0.6MPA Consumption: 0.3M3/MIN |
Scope of work |
A type :5-15ML B type :10-75ML C-type :20-150ML D-type :50-300ML E-type :100-500ML F type :200-1000ML |
Production capacity |
10-80 times / min |
Filling accuracy error |
<2% |
Table adjustable height |
100MM |
Tank Capacity |
20L, 30L, 40L, 50L |
Filling the container diameter |
according to the material viscosity and filling volume set |
*Note: The above parameters for reference only. The machine constantly upgrades parameters may cause the actual discrepancies, please understand.
Product Features
__________________________________________________________________________________________________
lThe machine can be used for explosion-proof units.
lMainly used for quantitative filling of water, oil, lotion, paste-like material. According filling needs, adjustable work surface lift.
lFilling volume 5-1000ML, Divided into six series :A, B, C, D, E, F.
lFeeding mode: Normal Gravity / automatic suction type Choose one.
lControl: pneumatic control
Workplace
__________________________________________________________________________________________________
1.Laboratory
2.Industrial production operations with continuous
Pictures
