Specifications
Aluminum Titanium Ceramic Rod of Ceramic Coating MaterialGood resistance to mechanical rriction
Very good abrasion resistanc
Aluminum Titanium Ceramic Rod of Ceramic Coating Materials: saint-gobain Ceramic materials
• Vailable Rod Size
Kingsky™ AT KS-05 1/4" Diameter x 24"
Diameter: 1/4"± 0.0012" (6.35mm±0.03mm ) Length: 24" ~24.4" (610mm~620mm)
• Properties
Good Resistance to Mechanical Friction
Good Abrasion Abrasion Resistance
• Typical Chemical Composition(%)
AI2O3 49.01
TiO2 49.11
SiO2 0.82
CaO 1.01
Fe2O3 0.03
MgO 0.02
• Color and Weight
Color: Yellow
Weight: 41g/pcs
• Hardness
Hardness: HV1000~1200
• Applications
Hot Metal Extrusion Dies
• Coating Features
Deposit Efficiency: 61%
Total porosity: <8.6%
Bulk Density: 4.8g/cc
Coating Hardness: HV1100
Kingsky™ AT 1/4" (KS-05)
Rods Packaged in Tubes: 50 rods
10 tube per wooden box: 500 rods
The company have been awarded GB/T 19001-ISO9001 Quality System Certificate.
All our products are subjects to a strict inspecion.
Kingsky™ as ceramic rod manufactory will provide first class, timely technical services in order to achieve customer statisfaction.
Ningbo Kingsky Thermal Spray Ceramic Rod co., ltd are one of China's leading manufacturers and supplier's of thermal spray ceramic rod and thermal spray industrial coating services.
What is Kingsky™ Ceramic Rod Samples Policy?
To help you with your testing of the Kingsky™ Ceramic Rod, Kingsky is pleased to offer a limited amount of ceramic rod samples to qualified customers.
Usually 10 pcs ceramic rod sample are valid.
No Free samples! it needs a limited amount cost of the samples (include shipping cost by DHL or Fedex) as below:
If you'd like to order ceramic rod samples or have any questions, please don't hesitate to contact us
Worth knowing:
Properties of Aluminum Oxide Ceramic (Al2O3)
•Very good electrical insulation (1x1014 to 1x1015 Ωcm)
•Moderate to extremely high mechanical strength (300 to 630 MPa)
•Very high compressive strength (2,000 to 4,000 MPa)
•High hardness
•Moderate thermal conductivity (20 to 30 W/mK)
•High corrosion and wear resistance
•Good gliding properties
•Bioinert and food compatible
Ceramic Rod Flame Spraying
Products spray by Aluminum Oxide (Al2O3)
Numerous chemistries are available, each offering unique advantages. Aluminum oxide coatings can be engineered to improve dielectric performance (using nearly-pure AlO3), to provide electrical insulation, to boost corrosion or wear resistance (using titanium oxide additives), to reduce or eliminate current transfer arc erosion, and more, based on customer requirements for part performance
•Ball Heads
•Ballistic Protection Components
•Bearing Technology in Automotive Engineering
•Drawing Tools
•Dry-pressed Substrates (Ceramics)
•Vacuum Isolators
•Metalized Substrates (Ceramics)
•Protective Ceramics (Ballistics)
•Pumps, Components for
•Seal and Regulator Discs
•Seal Rings, Bearings and Sealing
•Sealing Technology (Seal Rings, Bearings)
•Stamped Substrates (Ceramics)
•Textiles Industry
•Vacuum Accessory Components
•Wear Protection, Components for
•Wire Drawing, Components for
saint-gobain Ceramic materials
