Help CenterBlock Crack Width Meter
Related Products
Specifications
Block Crack Width MeterHigh light supper lager LCD
Test range:0.02-2.0mm
Portable type
digital hand type
Block Crack Width Meter
as a new professional concrete structure measurement instrument for the crack width and the microcosmic defects on surface, against the traditional crack microscope inconvenient for observation, based on the Standard of Dangerous Building Appraisal GJG125-99 about relative request of evaluate the house dangerous point with the crack width.
Application:
Mainly used for testing the crack width of bridge, channel, concrete plate, metallic surface.
Feature:
1.High light supper lager LCD, display the crack image’s edge clearly and read conveniently
2.The newest technology of formation of image of electronic, recover the original crack actually.
3.The microcosmic camera measurement probe is made of totally stainless steel, resistance to wear and drop.
Specification:
Amplified multiple: 40(standard) 50(optional)
Test range:0.02—2.0mm
Interpolation 0.01mm
Voltage: 12VDC (8 recharger battery)
Size: 270×15×50(mm)
Measurement probe: 40×40×60(mm)
Weight: 800g
Standard setup:
High light supper lager LCD Microscopic camera measuring probe,
signal transfer line, Standard scale plate calibrated by MIN,
Charger, Manual, Software ,Case
Packing List:
1. Main frame 1 set
2.Probe 1pcs
3. Cable 1 pcs
4.Rubber bag 1 pcs
5. Test board 1 pcs
