SUS316 Stainless Steel Wire Mesh(22 years' Factory)
We offer a wide range of impeccable woven stainless steel wire mesh, which is available in various sizes and dimensions. We have firmly positioned ourselves as one of the supreme stainless steel wire mesh manufacturers in India. High temperature tolerance, durability, high flow rate are some of the unique features of our woven steel wire mesh.
General Use: Stainless steel wire mesh, with its excellent resistance against acid, alkali, heat and corrosion, find extensive uses in processing of oils, chemicals, food, pharmaceuticals, also sorting and screening of solid, liquid and gas in mine, metallurgy, airspace, machine making, etc.
Specification List of Stainless Steel Wire Mesh | |||||||
Mesh/Inch |
Wire Diameter(mm) |
Aperture (mm) |
Filtration Area% |
Mesh/Inch |
Wire Diameter(mm) |
Aperture |
Filtration Area% |
5 |
1.00 |
4.08 |
64 |
100 |
0.11 |
0.144 |
32 |
6 |
0.90 |
3.33 |
62 |
120 |
0.09 |
0.122 |
33 |
8 |
0.70 |
2.47 |
61 |
150 |
0.065 |
0.104 |
38 |
10 |
0.50 |
2.04 |
64 |
200 |
0.05 |
0.077 |
37 |
12 |
0.50 |
1.62 |
59 |
200 |
0.04 |
0.084 |
47 |
14 |
0.50 |
0.50 |
52 |
250 |
0.04 |
0.062 |
37 |
16 |
0.35 |
1.24 |
61 |
250 |
0.035 |
0.067 |
43 |
18 |
0.28 |
1.13 |
64 |
250 |
0.03 |
0.072 |
50 |
20 |
0.35 |
0.92 |
52 |
300 |
0.04 |
0.045 |
28 |
24 |
0.35 |
0.71 |
45 |
300 |
0.03 |
0.055 |
42 |
28 |
0.35 |
0.56 |
38 |
325 |
0.035 |
0.043 |
30 |
1.What payment term you accept, and usually do?
We usually accept and do T/T payments,30% deposit in advance,and the balance against the copy of BL.
We also accept L/C payment.
2.What's your MOQ and do the price relate to the quantity?
Our MOQ for wire is 1 ton,MOQ for mesh is 100 rolls. The price is diffenent , if the quantity is different.
3.If we want sample,how much do we need to pay?
A piece of mesh or 0-0.5kg wire is free,you just need to pay the freight.
4.If we just want a trial order, not a full container, how to ship them and what's the price?
If a order not a full container, then goods need to be shipped LCL. If you don't know how to deal, we can quotate you CIF price, and ship the goods to the designated port.
