Partition wall system metal profiles (exclusive for Elst wall system)
Top partition wall system metal profiles use domestic high-quality continuous hot-dip galvanized steel strip as raw material, is a kind of high-quality product manufactured by applying advanced technology and rolling and cold bending process. It belongs to European and American lightweight metal framing system with simple structure and less accessories.
Applicable scope:
- Widely applied in inner partition walls of various commercial and civil buildings like shopping mall, hotel, office building, residential building, etc.
- Profiles with different specifications and arrangements can form lightweight partitions with different thickness and performance according to requirements for fire prevention, sound insulation and wall height.
- Simple processing of stud and adoption of simple construction details can form firm and beautiful door frame and window frame structure.
- By bending top an bottom U channels, arranging vertical studs and adopting special installation methods of plasterboard, beautiful curved wall can be created very easily.
- It can be applied in elevator shaft and duct shaft in combination with reinforcing measures by lightweight steel structure.
Features:
- made of corrosion resistant high-quality continuous hot-dip galvanized steel strip, the double-sided galvanization grammage exceed100g/m2
- 50mmwide flange design makes it easier to fasten screw and reduce joint cracking
- Rib reinforcement design for lateral flanges increases the rigidity of stud and reduces deformation, and can reach required stiffness without need of horizontal bracing support as in tradition lightweight steel framing partition system.
- Artful unequal flange width design offers convenience for boxing and extending of studs. It is applicable to parts requiring reinforcement, like door frame.
- Fully imported Italian production line ensures high accuracy and minimum tolerances;
- geometrical sizes designed according to Chinese architectural characteristics and standards.
Product specification:
Stud specification
Length (mm)
Weight (kg/m)
Package (pieces/bundle)
QC50*50*0.6
3000/4000
0.764
128
QC75*50*0.6
3000/4000
0.882
120
QC100*50*0.6
3000/4000
0.912
80
QC100*50*0.7
3000/4000
1.006
80
QU50*40*0.6
3000/4000
0.624
128
QU75*40*0.6
3000/4000
0.740
120
QU100*40*0.6
3000/4000
0.832
80
QU100*40*0.7
3000/4000
0.867
80
