GIC1.5KW/2KW/3KW/5KW/10KW/15KW TUV/UL WIND TURBINE ON GRID INVERTER

GIC1.5KW/2KW/3KW/5KW/10KW/15KW TUV/UL WIND TURBINE ON GRID INVERTER thumbnail-1
GIC1.5KW/2KW/3KW/5KW/10KW/15KW TUV/UL WIND TURBINE ON GRID INVERTER photo-1
US$ 1,000 - 1,000 MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
Ginlong
Model Number:
1- 10kw
Contact Supplier Request Quote Chat Now
Qingdao Techwell Power Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo /Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name Ginlong
Model Number 1- 10kw
Output Power 1 - 200KW
Output Type Single
Weight 30kg
Input Voltage 40v
Output Voltage 500v
Type Other, DC/AC Inverters, on/in grid/Wind
Output Current DC-AC
Size Smart Small

Specifications

Grid tie Inverter
- Max efficiency 97%
- Input voltage range from 30V to 750V
- PWM inverter technology
- IEC, UL

Wind Turbine Grid Tie  Inverter 1.5KW/2KW/3KW/5KW/10kw/15kw

TUV/ UL / CE aproved inverter

 GIC1.5KW/2KW/3KW/5KW/10KW/15KW TUV/UL WIND TURBINE ON GRID INVERTERGIC1.5KW/2KW/3KW/5KW/10KW/15KW TUV/UL WIND TURBINE ON GRID INVERTER



Model
GCI-1.5K
GCI-2K
GCI-3K
GCI-3.5K
GCI-5K
GCI-10K
Energy Source
Wind
PV
Wind
PV
Wind
PV
Wind
PV
Wind
PV
Wind
PV
The max DC input voltage:
450V
600V
600V
600V
600V
1000V
MPPT operation range:
30-400V
30-540V
100-500V
30-540V
100-500V
30-540V
100-500V
30-540V
100-500V
30-750V
250-820V
DC nominal voltage:
250V
400V
The max dc input current:
9Adc
9Adc
20Adc
10Adc
24Adc
12Adc
25Adc
15Adc
33Adc
22Adc
Number of MPP trackers/strings per MPP Tracker:
1/1
1/1
1/1
2/1
1/1
2/1
1/1
2/1
1/1
2/3
Rating output power:
1.5kW
2kW
3.0kW
3.5kW
5kW
10kW
The transient max power:
1.7kW
2.2kW
3.3kW
3.8kW
5.5kW
11kW
Rating grid voltage:
230Vac
230Vac
230Vac
230Vac
230Vac
400Vac
The grid voltage range:
180~270Vac(adjustable)
340~450Vac
(adjustable)
Operation phase:
single
Three phase
Rating grid output current:
6.25Aac
8.7Aac
13.0Aac
15.7Aac
21.74Aac
14.5Aac
Output power factor:
>0.99
Grid current THD:
Total THd<4%
The dc injection current:
<10mA
<10mA
<20mA
<20mA
<50mA
<10mA
Rating grid frequency:
50/60Hz(±3Hz)
Efficiency:
>95%
>95%
>96.5%
>97.5%
>97%
>97.5%
Protection:
DC reverse-polarity protection; AC short circuit protection;
islanding protection; temperature protection. Etc.
Size(mm):
520W×385H×120D
520W×385H×150D
400W×580H×170D
400W×740H×170D
400W×800H×170D×2
Weight:
12.7kG
16kG
23kG
50kG
Topology:
Transformerless
Internal consumption:
<5W
(NO wind)
<6W
(NO wind)
<1W
(Night)
<6W
(NO wind)
<1W
(Night)
<6W
(NO wind)
<1W
(Night)
<6W
(NO wind)
<1W
(Night)
<6W
(NO wind)
<1W
(Night)
Running temperature:
-25°C~60°C
Ingress protection:
IP65
Interface:
RS485/Bluetooth
Design lifetime:
>20 years
Operating Range Utility Frequency (Hz):
47-52 or 57-62 (ajustable)
Utility Monitoring:
Islanding protection VAC, FAC in accordance with UL 1741, G83/1, AS4777
Operation Surroundings Humidity:
0~95%
EMC:
EN61000-6-1:2007
EN61000-6-3:2007

GIC1.5KW/2KW/3KW/5KW/10KW/15KW TUV/UL WIND TURBINE ON GRID INVERTERGIC1.5KW/2KW/3KW/5KW/10KW/15KW TUV/UL WIND TURBINE ON GRID INVERTERGIC1.5KW/2KW/3KW/5KW/10KW/15KW TUV/UL WIND TURBINE ON GRID INVERTERGIC1.5KW/2KW/3KW/5KW/10KW/15KW TUV/UL WIND TURBINE ON GRID INVERTERGIC1.5KW/2KW/3KW/5KW/10KW/15KW TUV/UL WIND TURBINE ON GRID INVERTERGIC1.5KW/2KW/3KW/5KW/10KW/15KW TUV/UL WIND TURBINE ON GRID INVERTER
