NAKIN AD-Series air dryer equipment for transformer
Application:
Series AD air dryer device is special for drying the electric equipments and providing the dry air. When operation and maintenance, electrical equipments, such as transformer and reactor, are quite easy to be moistened. Series AD air dryer supplies dry air to solve this problem, anoxia asphyxia will never happen to maintenance people. It’s more safe, reliable, convenient and economical than by using bottled gas. It is not influenced by bad weather conditions, especially for overnight working, just to fill 0.02-0.03MPa dry air into equipment after sealing all flanges. Electric equipments Oil filling and oil drainage is unnecessary, which can shorten working period and improve maintenance effect. During oil filtration, it can fill dry air into oil equipment block and oil to improve oil insulation and decrease the moisture.
Series AD air dryer adopts low pressure oil-less compressed system and low-temperature condensation moisture removal technology, with the merits of small dimension, light weight, easy operation, energy saving and high reliability.
Technical parameters:
Model |
AD-5 |
AD-10 |
AD-20 |
AD-40 |
AD-100 |
AD-200 |
Air supply m3/h |
5 |
10 |
20 |
40 |
100 |
200 |
Dew point |
-55°C to -70°C |
|||||
Air pressure |
0.02-0.04Mpa |
|||||
Power supply |
380V 50Hz 3Ph |
|||||
Power (KW) |
0.6 |
1 |
2 |
3.5 |
8.0 |
12.0 |
L×W×H(mm) |
800× |
1000× |
1200× |
1400× |
1500× |
1700× |
Inlet/outlet(mm) |
10 |
15 |
25 |
32 |
40 |
50 |
Weight (Kg) |
100 |
160 |
280 |
430 |
720 |
1000 |
NAKIN Company products list as following:
ZY-high effective vacuum transformer oil purifier, oil filtration
ZYD-Double stages Vacuum insulating/transformer oil purifier, oil treatment, oil purification
ZYM-Mobile/trailer type Vacuum transformer oil treatment, oil filtration machine
TY-Vacuum Turbine oil purifier, oil treatment Plant
TJ-Coalescence and separating light/fuel/gasoline oil filter, oil purifier machine
TYA-Vacuum Lubricating oil purifier/hydraulic oil purification
TYK- Phosphate ester fire-resistant oil purifier, oil filtration machine
JZS-Engine oil regeneration system, waste oil recycling
JZC-Waste Oil Distillation System
JYWL-Horizontal-closed type filtration device
TPF-Waste cooking oil recycling machine
BZ-Transformer oil regeneration device, oil purifier
PF-Plate pressure turbine/transformer/engine/diesel/hydraulic oil filter, oil purifier machine
JL-Portable turbine/lube/insulating oil purifier, oil filtering, oil filter
NKVW-Vacuum pump system
IIJ-II-BDV oil tester, insulating oil dielectric strength tester
NKEE-Oil moisture sensor, water content sensor
