SMC sheet molding compound production line,electril meter box making machine,manhole cover making machine
This machine produces SMC by forming a sandwich structure which outside are two layer films and in the middle are polyester resin, fiber glass, CaCO3 powder, release agent, hardening agent etc. It's durable with advanced technical, highly automation and outputs. There are four parts of the SMC Machine: the main compacting part, the final SMC taken-up part, the cutting fiberglass yarn part and electrical control part. It adopts PLC digital control system. The compacting part is pneumatic type, controlled by air compressor. There are three width machine: 500mm, 1000mm, 1200mm
Model |
SMC500 |
SMC1000 |
SMC1200 |
Sheet Width |
500mm |
1000mm |
1200mm |
Thickness |
2-3mm |
2-4mm |
2-5mm |
Speed |
12m/min |
||
One Shift Outputs(8hous) |
4tons |
8tons |
9tons |
Electric Control |
Frequency Control or PLC Digital Control System |
||
Chain Belt Corrector |
Manual Operation or Automatic Operation |
||
Fiber Content |
18-30 |
||
Staple Length |
25mm |
||
Drive System |
V belt |
||
Total Power |
7.5kw |
7.5kw |
9kw |
Length*Width*Height mm |
6000*1300*1800 |
6000*1900*1800 |
6000*1900*1800 |
Weight |
2500kg |
3000kg |
3000kg |
We are Laizhou Yuanda Machinery company. we main manufacture chemical, plastic and engineering machinery , our products are competitive in international market, enjoy great popularity in many foreign importers, exported to many countries such as Thailand, Saudi Arabia, and others ,with a competitive price and quality , getting good reputation.
The characteristic of our products are reasonably structured wear well easy maintenance and operation well after service and so on. You can log our website. We will be pleased to receive your inquiry for any items interesting you. Then we will send you the more detail information you need. Hope we have opportunity to establish business relations, and have a successful and long cooperation.
1) Main Parts: Cutting Part, Host, Curly Part, Electric Control Part
Cutting Part: variable speed motor; helical cutting roller (increase work life of rubber roller and blade); If high fiberglass content is required, such as above 30%, double roller can be designed on the machine.
Host: frequency conversion motor; Materials are compacted by belt chains (SS) which are controlled by pneumatic form
Curly Part: torque motor driven; speed can be adjusted at any time; automatic; effort saving
Electrical Control Part: central control to meet production requirements; components are well known brand.
