SUDA CO2 Laser Rubber Engraving Machine --SL9060 Sample

Name: SUDA CO2 Laser Rubber Engraving Machine --SL9060 Sample
Brand: SUDA
SKU: 144390732

US$ 3,500 - 5,000 MOQ: 1 Set

Key Specifications

Laser Type:

CO2 Laser

Q-Switch:

Yes

Style:

Stationary

Tongxing Technology Development Co., Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Laser Type CO2 Laser

Q-Switch Yes

Style Stationary

Certification CE

Place of Origin Anhui, China

Brand Name SUDA

Model Number SL9060

Specifications

SUDA Laser engraving cutting machine
Applicable to material :Acrylic ,PVC board woody products,Bamboo ware
CO2 laser tube

Laser engraving/cutting machine SL6090

Laser power :	60W
Laser type:	SL6090
Power supply:	AC220V±10%,50HZ
Working area:	900*600mm
Max cutting speed:	200mm/sec
Max engraving speed:	2000mm/sec
Worktable:	Lifting platform (optional )
motor	Standard stepper, SERVO import from Japan ( optional)
Locating precision:	0.1mm
Min shaping character:	Engrving 0.8mm, cutting 2mm
Operating temperature:	0°c-45°c
Work degree of humidity	5-95%(have no Ning water)
Resolution ratio:	0.025mm
Control configuration:	Advanced DSP controlling system
Data transfer interface:	USB flash disk / directly from computer
System environment:	Above Window 2000, window XP
Cooling way:	Water cooling
Graphic format supported:	BMP,GIF,JPGE,PCX,TGA,TIFF,PLT,CDR,DMG,DXF, etc.
Compatible software	Transmit files directly form Coreldraw, AutoCAD, etc.
Cutting thickness	20mm
Color separation	200
Sloping engraving	90°--180°
Cuts off the water supply the protection	yes
Machine dimention	164011201380mm
Red point as standard	not
Air pump as standard	Yes
Gross weight	370kg
packing	Standard non-woody
