compare with other factory's quilting machine our machine is High accuracy and long life.Especially for the garments quilting.
CSDB64"-3 Quilting Machine
1. D: Digital control model; B: Big shuttle (HQ10)
2.64": 64inch width (1626mm)
3.3: Three needle row
4. Overall Dimensions: 3800*1200*1650mm
5: Weight: 2600kg
6: Running speed: 200-500r/m
7: Needle distance: 25.4mm
8. Rating power: 3.5kw
9. Thickness: ≤30mm
10. Max pattern size is 12inch by 12inch
11. The shuttle size is HQ10 (Japanese) .
*this quilting machine Adopting digital control program.
*Saddles and rollers driven by Panasonic servo devices.
*The revolution of the spindle controlled by Panasonic frequency conversion control devices.
*Large number of built-in quilting patterns for your choice.
*Easy and quick make new designs.
*360 degrees quilting .
*Tack and jump function included
*stitches between 2mm-6mm adjustable.
*Function of pattern compensation, an effective solution to the distortion of patterns when quilting thick materials.
*Simulation display of quilting.
*Automatic needle raising and location brake system.
*Function of automatic stop on breaking of thread (optional)
*Infrared sensors to guarantee the safety of the operator.
HS Code: |
8452 |
Trademark: |
ChiShing |
Model: |
CSDB64"-3 |
Standard: |
ISO9000-2000 ;CE |
Productivity: |
30-60sets per month |
Origin: |
China |
Packing: |
Export Packing |
Min. Order: |
1 |
Transportation: |
By Sea. |
|
|
