42.5V 4A 4A E-Bike Scooter Car Li-ion Battery Charger With PSE

Name: 42.5V 4A 4A E-Bike Scooter Car Li-ion Battery Charger With PSE
Brand: Xinsu global
SKU: 157165204

US$ 29.2 - 30.2 MOQ: 100 Pieces

Key Specifications

Brand Name:

Xinsu global

Place of Origin:

China

Model Number:

XSG4254000

Xinsu Global Electronic Co.Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen &Hongkong

Delivery Detail:

20 days

Brand Name Xinsu global

Place of Origin China

Model Number XSG4254000

Type Electric

Use Standard Battery

product description

Product Electronics Parameter
Product name	42.5V 4A 5A E-Bike scooter Car li-ion battery charger with PSE
Model number	XSG4254000
AC input	Input Voltage range:	90~264Vac
	Reted input voltage:	100~240Vac
	InputFrequency Range:	47~62hz
	Input current max:	1.3A
	Inrush current:	35A Max/240V
	Efficiency:	>89%
	No load Input power
	Leakage current:
DC output	Max charging voltage:	42.5V
	Output voltage tolerance:	5%
	Max charging current:	0~4A
	Ripple and noise:
	Charging mode:	3- stage, CC,CV,trickle charging
	Cut off current when charged full	Optional
	LED indicator	Charging: Red, Charged full: Green
	Charging current when charged full
Protection	Over current protection	PASS
	Over voltage protection
	Short circuit protection
	Over Temp protection
	Anti-flow protection
Environment	Operating Temp:	0℃~+45℃
	Storage Temp:	-30℃~+70℃
	Relative Humidity:	10%~90%
	Vibration and shock	Meet MIL-STD-810D
Safety	Safety standard	EN60950,EN61558,EN60335
	EMC/EMI	Meet FCC CLASS B,EN55022 CLASS B.
	EMS	EN61000-4-2
		EN61000-4-3
		EN61000-4-4
		EN61000-4-5
	A Harmonic source	Pass
	HI-pot: Primary to Secondary	3KVAC,5mA,60s
	Drop Test	As per UL regulation
	Burning test	100%,4-5 hours
Life	MTBF	50000 hours
Life	Warranty	3 years
