Full Automatic Mineral Water Filling Machine/bottled Filling Line Three in One Unit

US$ 10000 - 1000000 MOQ: 1 Piece

Key Specifications

Brand Name:

Place of Origin:

China

Model Number:

CGF

ZhangJiagang Baixiong Machinery CO.,LTD.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

30 days

Brand Name BX

Place of Origin China

Model Number CGF

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Warranty 1 year

Weight depending on different models

Dimension(L*W*H) depending on different models

Condition New

Voltage according to clients' requirements

Power(W) depending on different models

Processing Types water

full automatic mineral water filling machine/bottled filling line three in one unit

1) The machine has compact structure, complete control system, easy operation and high degree of automation

2) To change bottle shape, the operator only needs to replace the star-wheel, inlet bottle screw and arc guide plate

3) The parts contacting media are made from 304 SUS and have no process blind angles to enable easy cleaning

4) High speed filling valve, guarantees liquid has precise level and no waste is incurred

5) The capping head applies a constant magnetic torque device to secure capping quality and prevent damage to the bottle cap

6) The control system has the function of control producing speed, cap shortage detection, bottle block auto stop and production counting

7) The machine applies a highly effective cap arranging system that has complete self control and protective device

8) The machine is equipped with a complete overload protection device that can secure equipment and the operator effectively

9) Main electric components and pneumatic components apply world famous brand products

10) The machine's operation is controlled by an advanced touch-screen that can fulfill human-machine communication.

Model	CGF24-24-8	CGF32-32-10	CGF40-40-12	CGF50-50-12
Number of filling ,washing and capping heads	24-24-8	32-32-10	40-40-12	50-50-12
Production capacity (500ml)(B/H)	10000	14000	18000	24000
Suitable bottle specification(mm)	φ=50-90 High150-310
Washing pressure(MPa)	0.25
Motor power(kw)	4.1	5.6	7.5	10.8
Overall dimensions(mm)	305020602100	405023002100	430033002500	472035502750
Weight (kg)	4000	5000	7500	8500
